Description

Using 2 bytes for every type provides:

0..32766 for unsigned coordinates.
0..32767 for unsigned distances.
-32768..32767 for signed distances.

This is way enough for any ZX need, even in large ZX screens.

Checking that the values are within those ranges is left to the user of the library. This library only asserts that these types are integral/signed/ unsigned appropriately.

The verbosity of the Coordinate/Distances system in this module is due to these facts: i) to enable type differentiation of the diverse coordinates and distances even when their numerical types may coincide ; ii) it is not more work for the user, but to the programmer of this library; iii) it prevents common errors in the use of diverse coordinate/distances types (pixels and chars), that are usually used at the same time on the same screen.

There are three coordinate systems supported in this module:

-PixelCoord/PixelDist/IntDist: pixel coordinates in the drawable part of
the ZX screen. (0,0) are assumed to be in the top-left and grow downward
from left to right, thus they are always positive.

-CharCoord/CharDist/IntDist: char coordinates in the drawable part of
the ZX screen. (0,0) are assumed to be in the top-left and grow downward
from left to right, thus they are always positive.

-BorderCoord/BorderDist/IntDist: pixel coordinates in the border of the
ZX screen that are of the same pixel size as those on the drawable.
(0,0) are at the (0,0) pixel coordinates of the drawable part
of the screen, thus the top border section gets negative y-coordinates,
the left border section gets negative x-coordinates, the right border
section gets positive, beyond drawable pixel x-coordinates, and the
bottom section gets positive, beyond drawable pixel y-coordinates.

Collaboration diagram for Coordinate systems for the screen:

Typedefs
using	zxeco::PixelCoord = uint16_t
	Represent both x and y screen pix coordinates. More...

using	zxeco::CharCoord = uint16_t
	Represent both x and y screen char coordinates. More...

using	zxeco::PixelDist = uint16_t
	A distance measured in screen pixels. More...

using	zxeco::CharDist = uint16_t
	A distance meadured in screen chars. More...

using	zxeco::IntDist = int16_t
	Positive and negative distances on screen. More...

using	zxeco::BorderCoord = int16_t
	Represent both x and y pix coords in border. More...

using	zxeco::BorderDist = uint16_t
	A distance measured in pixels in the border. More...

using	zxeco::CharCoordT::type = CharCoord
	Numerical type corresponding to this class. More...

using	zxeco::PixelCoordT::type = PixelCoord
	Numerical type corresponding to this class. More...

using	zxeco::CharDistT::type = CharDist
	Numerical type corresponding to this class. More...

using	zxeco::CharDistT::coord_typeT = CharCoordT
	Corresponding coord type trait. More...

using	zxeco::PixelDistT::type = PixelDist
	Numerical type corresponding to this class. More...

using	zxeco::PixelDistT::coord_typeT = PixelCoordT
	Corresponding coord type trait. More...

using	zxeco::IntDistT::type = IntDist
	Numerical type corresponding to this class. More...

using	zxeco::BorderCoordT::type = BorderCoord
	Numerical type corresponding to this class. More...

using	zxeco::BorderDistT::type = BorderDist
	Numerical type corresponding to this class. More...

using	zxeco::BorderDistT::coord_typeT = BorderCoordT
	Corresponding coord type trait. More...

using	zxeco::Cursor< WRES, HRES >::WidthType = WRES
	Type used for the width dimension. More...

using	zxeco::Cursor< WRES, HRES >::HeightType = HRES
	Type used for the height dimension. More...

using	zxeco::CharCursor = Cursor< CharCoordT, CharCoordT >
	Shortcut for this kind of cursor. More...

using	zxeco::PixCursor = Cursor< PixelCoordT, PixelCoordT >
	Shortcut for this kind of cursor. More...

using	zxeco::CharPixCursor = Cursor< CharCoordT, PixelCoordT >
	Shortcut for this kind of cursor. More...

using	zxeco::BorderCursor = Cursor< BorderCoordT, BorderCoordT >
	Shortcut for this kind of cursor. More...

using	zxeco::Area< WRES, HRES >::WidthType = WRES
	Type used for the width dimension. More...

using	zxeco::Area< WRES, HRES >::HeightType = HRES
	Type used for the height dimension. More...

using	zxeco::Area< WRES, HRES >::CursorType = Cursor< typename WRES::coord_typeT, typename HRES::coord_typeT >
	Cursor. More...

using	zxeco::CharArea = Area< CharDistT, CharDistT >
	Shortcut for this kind of area. More...

using	zxeco::PixArea = Area< PixelDistT, PixelDistT >
	Shortcut for this kind of area. More...

using	zxeco::CharPixArea = Area< CharDistT, PixelDistT >
	Shortcut for this kind of area. More...

using	zxeco::BorderArea = Area< BorderDistT, BorderDistT >
	Shortcut for this kind of area. More...

using	zxeco::Rect< WRES, HRES >::cursor_type = Cursor< typename WRES::coord_typeT, typename HRES::coord_typeT >

using	zxeco::Rect< WRES, HRES >::area_type = Area< WRES, HRES >

using	zxeco::CharRect = Rect< CharDistT, CharDistT >
	Shortcut for this kind of rectangle. More...

using	zxeco::PixRect = Rect< PixelDistT, PixelDistT >
	Shortcut for this kind of rectangle. More...

using	zxeco::CharPixRect = Rect< CharDistT, PixelDistT >
	Shortcut for this kind of rectangle. More...

using	zxeco::BorderRect = Rect< BorderDistT, BorderDistT >
	Shortcut for this kind of rectangle. More...

using	zxeco::DimsGraphic< HEIGHTRESOL >::CursorType = Cursor< CharCoordT, typename HEIGHTRESOL::coord_typeT >

using	zxeco::DimsGraphic< HEIGHTRESOL >::AreaType = Area< CharDistT, HEIGHTRESOL >

using	zxeco::DimsGraphic< HEIGHTRESOL >::RectType = Rect< CharDistT, HEIGHTRESOL >

using	zxeco::Bitmap::BaseGr = DimsGraphic< PixelDistT >

using	zxeco::Attrmap::BaseGr = DimsGraphic< CharDistT >

using	zxeco::DoubleGraphic::NumDithLevels = uint8_t
	Type for storing number of dithering levels. More...

using	zxeco::DoubleGraphic::DitheringSystem::DitherLevel = NumDithLevels

Enumerations
enum class	zxeco::LinearGraphic::GraphOp : unsigned char { zxeco::LinearGraphic::GraphOp::COPY , zxeco::LinearGraphic::GraphOp::INV , zxeco::LinearGraphic::GraphOp::OR , zxeco::LinearGraphic::GraphOp::INVOR , zxeco::LinearGraphic::GraphOp::AND , zxeco::LinearGraphic::GraphOp::INVAND , zxeco::LinearGraphic::GraphOp::XOR , zxeco::LinearGraphic::GraphOp::INVXOR }
	Possible operations on Graphics. More...

enum class	zxeco::DoubleGraphic::PNGConversionMode { zxeco::DoubleGraphic::PNGConversionMode::ToNearestPlain , zxeco::DoubleGraphic::PNGConversionMode::Dither }
	Modes of conversion of PNG images into DoubleGraphic. More...

enum class	zxeco::DoubleGraphic::PNGConversionSubmode { zxeco::DoubleGraphic::PNGConversionSubmode::None , zxeco::DoubleGraphic::PNGConversionSubmode::FixedPattern , zxeco::DoubleGraphic::PNGConversionSubmode::Noise }
	Submode of conversion of PNG images into DoubleGraphic. More...

Functions
constexpr CharCoord	zxeco::charOfPixelX (PixelCoord pc) noexcept
	Conversion from an x-PixelCoord to CharCoord. More...

constexpr CharCoord	zxeco::charOfPixelY (PixelCoord pc) noexcept
	Conversion from an y-PixelCoord to CharCoord. More...

constexpr PixelCoord	zxeco::firstPixelInCharX (PixelCoord pc) noexcept
	Get the PixelCoord of 1st pixel in the character of this x-PixelCoord. More...

constexpr PixelCoord	zxeco::firstPixelInCharY (PixelCoord pc) noexcept
	Get the PixelCoord of 1st pixel in the character of this y-PixelCoord. More...

constexpr unsigned char	zxeco::bitOfPixelX (PixelCoord pc) noexcept
	Get the bit position of the pixel of this x-PixelCoord. More...

constexpr PixelCoord	zxeco::pixelOfCharX (CharCoord cc) noexcept
	Conversion from an x-CharCoord to PixelCoord. More...

constexpr PixelCoord	zxeco::pixelOfCharY (CharCoord cc) noexcept
	Conversion from a y-CharCoord to PixelCoord. More...

constexpr PixelDist	zxeco::charDistToPixelDist (CharDist pc) noexcept
	Conversion from CharDist to PixelDist. More...

constexpr CharDist	zxeco::pixelDistToCharDist (PixelDist cc, bool toceil=true) noexcept
	Conversion from PixelDist to CharDist. More...

static const Cursor &	zxeco::Cursor< WRES, HRES >::theZero (void) noexcept
	< Return a reference to an inmutable zero cursorof this type. More...

static Cursor	zxeco::Cursor< WRES, HRES >::max (const Cursor &c0, const Cursor &c1) noexcept
	< Return a copy of the one of C0, C1 that is more to the right and below. More...

	zxeco::Cursor< WRES, HRES >::Cursor (typename WidthType::type xc, typename HeightType::type yc)
	Constructor, from the numerical coord types. More...

	zxeco::Cursor< WRES, HRES >::Cursor (WidthType xc, HeightType yc)
	Constructor from the trait coord types. More...

void	zxeco::Cursor< WRES, HRES >::newRow (void) noexcept
	Go down one row resetting x (y <- y + 1 & x <- 0). More...

void	zxeco::Cursor< WRES, HRES >::newCol (void) noexcept
	Go right one column (x <- x + 1). More...

void	zxeco::Cursor< WRES, HRES >::incRow (void) noexcept
	Go down one row without resetting x. More...

bool	zxeco::Cursor< WRES, HRES >::zero (void) const noexcept
	Return TRUE if the cursor is placed at (0,0). *‍/. More...

bool	zxeco::Cursor< WRES, HRES >::before (const Cursor &oth) const noexcept
	< Return TRUE if THIS is placed before OTH in the plane (linearly). More...

bool	zxeco::Cursor< WRES, HRES >::rightBelow (const Cursor &oth) const noexcept
	< Return TRUE if THIS is placed to the right and below of OTH. More...

IntDist	zxeco::Cursor< WRES, HRES >::xDiff (const Cursor &oth) const noexcept
	< Return the signed distance in X from OTH to THIS. More...

IntDist	zxeco::Cursor< WRES, HRES >::yDiff (const Cursor &oth) const noexcept
	< Return the signed distance in Y from OTH to THIS. More...

void	zxeco::Cursor< WRES, HRES >::addDiff (IntDist xdiff, IntDist ydiff) noexcept
	< Add the given signed distances to both coordinates. More...

bool	zxeco::Cursor< WRES, HRES >::operator== (const Cursor &oth) const noexcept
	< Return TRUE if both cursors are placed at the same place. More...

bool	zxeco::Cursor< WRES, HRES >::operator!= (const Cursor &oth) const noexcept
	< Unequality. More...

Cursor	zxeco::Cursor< WRES, HRES >::operator+ (const Cursor &oth) const
	< Return the sum of both cursors. More...

Cursor &	zxeco::Cursor< WRES, HRES >::operator+= (const Cursor &oth)
	Make the sum and return the result. More...

Cursor	zxeco::Cursor< WRES, HRES >::operator- (const Cursor &oth) const
	< Return the cursor THIS relative to OTH, or throw if result is negative. More...

Cursor &	zxeco::Cursor< WRES, HRES >::operator-= (const Cursor &oth)
	Make the substraction and return the result. More...

std::string	zxeco::Cursor< WRES, HRES >::to_string (bool withtype=true) const
	< Return a string with the textual information of the area. More...

PixCursor	zxeco::getPixCursor (const CharCursor &cc)
	Convert a char cursor to a pix cursor placed at the top-left of the former. More...

PixCursor	zxeco::getPixCursor (const CharPixCursor &cc)
	Convert a char-pix cursor to a pix cursor placed at the top-left of former. More...

CharPixCursor	zxeco::getCharPixCursor (const CharCursor &cc)
	Convert a char cursor to a char-pix cursor placed at the top of the former. More...

static const Area &	zxeco::Area< WRES, HRES >::theEmpty (void) noexcept
	Return a reference to an inmutable empty area of this type. More...

	zxeco::Area< WRES, HRES >::Area (typename WidthType::type w, typename HeightType::type h)
	Default constructor, from the numerical dist types. More...

	zxeco::Area< WRES, HRES >::Area (WidthType w, HeightType h)
	Constructor from the trait dist types. More...

	zxeco::Area< WRES, HRES >::Area (const CursorType &c0, const CursorType &c1)
	Constructor of the area within C0 (top-left) and C1 (bottom-right). More...

bool	zxeco::Area< WRES, HRES >::empty (void) const noexcept
	Return TRUE if the area is empty. More...

size_t	zxeco::Area< WRES, HRES >::area (void) const noexcept
	< Return the number of cells in the area. More...

bool	zxeco::Area< WRES, HRES >::containedInto (const Area &oth) const noexcept
	< Return TRUE if this area can be contained into OTH or if they are equal More...

Area	zxeco::Area< WRES, HRES >::operator+ (const Area &oth) const noexcept
	< Add width and height of OTH to THIS. More...

Area &	zxeco::Area< WRES, HRES >::operator+= (const Area &oth) noexcept
	< Add to THIS the width and height of OTH. More...

Area	zxeco::Area< WRES, HRES >::operator- (const Area &oth) const
	< Substract OTH dimensions from THIS dims and return the result, or throw More...

Area &	zxeco::Area< WRES, HRES >::operator-= (const Area &oth)
	Substract OTH from THIS and return THIS. Throw if error. More...

Area	zxeco::Area< WRES, HRES >::operator* (const Area &oth) const
	< Intersect OTH dimensions to THIS dims and return the result. More...

Area &	zxeco::Area< WRES, HRES >::operator*= (const Area &oth)
	Intersect OTH to THIS and return THIS. More...

bool	zxeco::Area< WRES, HRES >::operator== (const Area &oth) const noexcept
	< Equality. More...

bool	zxeco::Area< WRES, HRES >::operator!= (const Area &oth) const noexcept
	< Unequality. More...

std::string	zxeco::Area< WRES, HRES >::to_string (bool withtype=true) const
	< Return a string with the textual information of the area. More...

PixArea	zxeco::getPixArea (const CharArea &cc)
	Convert a char area to a pix area covering the same region on screen. More...

PixArea	zxeco::getPixArea (const CharPixArea &cc)
	Convert a char-pix area to a pix area covering the same region on screen. More...

CharPixArea	zxeco::getCharPixArea (const CharArea &cc)
	Convert a char area to a char-pix area covering the same region on screen. More...

static const Rect &	zxeco::Rect< WRES, HRES >::theEmpty (void) noexcept
	Return a reference to an inmutable empty rectangle of this type. More...

	zxeco::Rect< WRES, HRES >::Rect (const cursor_type &c=cursor_type{0, 0}, const area_type &a=area_type{0, 0})
	Default constructor: empty rectangle. More...

bool	zxeco::Rect< WRES, HRES >::empty (void) const noexcept
	Return TRUE if the rectangle area is empty. More...

bool	zxeco::Rect< WRES, HRES >::contains (const cursor_type &cur) const noexcept
	Return TRUE if CUR is inside the rectangle. More...

cursor_type	zxeco::Rect< WRES, HRES >::bottomRight (void) const noexcept
	< Return the coordinates of the bottom-right extreme within the rectangle More...

bool	zxeco::Rect< WRES, HRES >::applyConstrainedDiffs (IntDist &xdiff, IntDist &ydiff, const Rect &oth) noexcept
	Apply the given increments to the corner of THIS, keeping it within OTH. More...

Rect	zxeco::Rect< WRES, HRES >::compose (const Rect &reloth) const
	< Return the RELOTH region of THIS as a rectangle. More...

Rect	zxeco::Rect< WRES, HRES >::subRect (const cursor_type &reltopleft) const
	< Return the absolute sub-rectangle that starts at RELTOPLEFT within this More...

Rect	zxeco::Rect< WRES, HRES >::intersect (const Rect &oth) const noexcept
	Return the rectangle resulting from the intersection of this and OTH. More...

Rect	zxeco::Rect< WRES, HRES >::align_area (const area_type &areaneeded, char horalign, char vertalign) const
	Return the portion of this rectangle that contains AREANEEDED aligned. More...

bool	zxeco::Rect< WRES, HRES >::operator== (const Rect &oth) const noexcept
	< Equality. More...

bool	zxeco::Rect< WRES, HRES >::operator!= (const Rect &oth) const noexcept
	< Unequality. More...

std::string	zxeco::Rect< WRES, HRES >::to_string (bool withtype=true) const
	< Return a string with the textual information of the rectangle. More...

PixRect	zxeco::getPixRect (const CharRect &cc)
	Convert a char rect to a pix rect representing the same region on screen. More...

PixRect	zxeco::getPixRect (const CharPixRect &cc)
	Convert a char-pix rect to a pix rect representing the same region. More...

CharPixRect	zxeco::getCharPixRect (const CharRect &cc)
	Convert a char rect to a char-pix rect representing the same region. More...

std::string	zxeco::DoubleArea::to_string (void) const

std::string	zxeco::DoubleRect::to_string (void) const

template<LinearGraphic::GraphOp op>
static constexpr uint8_t	zxeco::LinearGraphic::doGraphOp (uint8_t b0, uint8_t b1) noexcept
	Return the result of doing operation OP on byte B0 with byte B1.

	zxeco::LinearGraphic::LinearGraphic (void)
	Default constructor: empty graphic.

	zxeco::LinearGraphic::LinearGraphic (size_t s)
	Construct an empty graphic of the given size, yet to be filled. More...

	zxeco::LinearGraphic::LinearGraphic (size_t s, uint8_t b)
	Construct a graphic of the given size filled with 1 byte (B).

	zxeco::LinearGraphic::LinearGraphic (uint8_t *bs, size_t s)
	Construct a graphic that is held externally (NO OWNERSHIP to this). More...

	zxeco::LinearGraphic::LinearGraphic (LinearGraphic &oth, size_t firstoff, size_t chunksize, size_t gap, size_t numchunks)
	Construct a graphic referring to part of another one (no ownership). More...

	zxeco::LinearGraphic::LinearGraphic (const LinearGraphic &)=delete

LinearGraphic &	zxeco::LinearGraphic::operator= (const LinearGraphic &)=delete

	zxeco::LinearGraphic::LinearGraphic (LinearGraphic &&og)

LinearGraphic &	zxeco::LinearGraphic::operator= (LinearGraphic &&og)

bool	zxeco::LinearGraphic::external (void) const noexcept
	Whether the object refers to part of another linear graphic. More...

bool	zxeco::LinearGraphic::owner (void) const noexcept
	Whether the object owns the graphical data. More...

size_t	zxeco::LinearGraphic::size (void) const noexcept
	Size in memory, in bytes. More...

bool	zxeco::LinearGraphic::oneByte (void) const noexcept
	Return TRUE if the graphic content is compressed into one byte. More...

uint8_t	zxeco::LinearGraphic::getByte (size_t offset) const
	Get the byte at the given offset, throwing if it is out of range.

uint8_t	zxeco::LinearGraphic::getByteUnsafe (size_t offset) const noexcept
	Get the byte at the given offset without checking out of range.

uint8_t *	zxeco::LinearGraphic::getAllBytes (void)
	Return a pointer to the data or throw if it is onebyte or external.

void	zxeco::LinearGraphic::setByte (size_t offset, uint8_t b)
	Change the byte at the given offset inside the data. More...

void	zxeco::LinearGraphic::setByteUnsafe (size_t offset, uint8_t b) noexcept
	Change the byte at the given offset without checking anything. More...

void	zxeco::LinearGraphic::setAllBytes (uint8_t b) noexcept
	Set all bytes of the graphic to the given value. More...

void	zxeco::LinearGraphic::merge (size_t destoffset, const LinearGraphic &oth, size_t origoffset, size_t howmany, GraphOp op=GraphOp::COPY)
	Merge HOWMANY bytes from OTH (at ORIGOFFSET) into this (at DESTOFFSET). More...

void	zxeco::LinearGraphic::mergeUnsafe (size_t destoffset, const LinearGraphic &oth, size_t origoffset, size_t howmany, GraphOp op=GraphOp::COPY)
	Merge HOWMANY bytes from OTH (at ORIGOFFSET) into this (at DESTOFFSET). More...

int	zxeco::LinearGraphic::compare (const LinearGraphic &oth, bool withinv=false) const noexcept
	Compare this graphic to OTH and return 1 if both are equal. More...

size_t	zxeco::LinearGraphic::similarity (const LinearGraphic &oth) const noexcept
	Return a measure of the bitmap similarity (bit by bit) between both. More...

std::string	zxeco::LinearGraphic::to_string (void) const
	Return a text with the info of the graphic.

void	zxeco::LinearGraphic::clear (void)

void	zxeco::LinearGraphic::reset (void)

void	zxeco::LinearGraphic::moveFrom (LinearGraphic &&og)

	zxeco::DimsGraphic< HEIGHTRESOL >::DimsGraphic (void)
	Default constructor: empty graphic. More...

	zxeco::DimsGraphic< HEIGHTRESOL >::DimsGraphic (const AreaType &a)
	Construct an undefined graphic of the given dimensions, to be filled. More...

	zxeco::DimsGraphic< HEIGHTRESOL >::DimsGraphic (const AreaType &a, uint8_t b)
	Construct a graphic of the given dimensions filled with one byte (B). More...

	zxeco::DimsGraphic< HEIGHTRESOL >::DimsGraphic (uint8_t *bs, const AreaType &a)
	Construct a graphic that is held externally (NO OWNERSHIP to this). More...

	zxeco::DimsGraphic< HEIGHTRESOL >::DimsGraphic (DimsGraphic &g, const RectType &region, bool copy=true)
	Construct a graphic that refers to a region within another one. More...

	zxeco::DimsGraphic< HEIGHTRESOL >::DimsGraphic (DimsGraphic &&oth)
	Move constructor. More...

DimsGraphic &	zxeco::DimsGraphic< HEIGHTRESOL >::operator= (DimsGraphic &&oth)
	Move assignment. More...

size_t	zxeco::DimsGraphic< HEIGHTRESOL >::offset (const CursorType &pos) const
	Get the offset corresponding to the given coordinates in the graphic. More...

CursorType	zxeco::DimsGraphic< HEIGHTRESOL >::coords (size_t offset) const
	Get the coordinates of the given offset, if it is valid, or throws. More...

uint8_t	zxeco::DimsGraphic< HEIGHTRESOL >::getByte (const CursorType &pos) const
	< Unhide the linear getByte() method hidden by the new getByte(). More...

void	zxeco::DimsGraphic< HEIGHTRESOL >::setByte (const CursorType &pos, uint8_t b)
	< Unhide the linear setByte() method hidden by the new setByte(). More...

void	zxeco::DimsGraphic< HEIGHTRESOL >::merge (const DimsGraphic &oth, const CursorType &pos, GraphOp mode=GraphOp::COPY)
	Merge OTH at the given coordinates of this object with the given mode. More...

HEIGHTRESOL::type	zxeco::DimsGraphic< HEIGHTRESOL >::scrollUp (typename HEIGHTRESOL::type howmany, typename HEIGHTRESOL::type upperrow, uint8_t fillb)
	Scroll HOWMANY rows of the graphic up, beginning at y-coord UPPERROW. More...

std::string	zxeco::DimsGraphic< HEIGHTRESOL >::to_string (void) const
	Return a text with the info of the graphic. More...

template<typename WIDTHRESOL , typename HEIGHTRESOL >
bool	zxeco::graphicDimensionsTooLarge (unsigned sx, unsigned sy) noexcept
	< Return TRUE if SX,SY are too large to fit in WITHRESOL,HEIGHTRESOL. More...

	zxeco::Bitmap::Bitmap (DesktopInterface &desktop, const std::string &pngfile)
	< Reuse all constructor from Gr<PixelDistT>. More...

	zxeco::Bitmap::Bitmap (uint8_t ascii, uint8_t *chartable=nullptr)
	Construct a bitmap for a ZX ascii char (including block-graphic ones).

void	zxeco::Bitmap::merge (const Bitmap &oth, const PixCursor &pos, GraphOp mode=GraphOp::COPY)
	< Unhide the base merge() method hidden by the new merge(). More...

std::string	zxeco::Bitmap::to_string (void) const
	Return a text with the info of the graphic. More...

void	zxeco::Attrmap::swapPaperInk (void)
	< Reuse all constructor from Gr<CharDistT>. More...

std::string	zxeco::Attrmap::to_string (void) const
	Return a text with the info of the graphic. More...

	zxeco::DoubleGraphic::DoubleGraphic (const CharArea &dims)
	Constructor for a given size in characters. More...

	zxeco::DoubleGraphic::DoubleGraphic (uint8_t bs, uint8_t as, const CharArea &a)
	Construct a graphic that is held externally (NO OWNERSHIP to this). More...

	zxeco::DoubleGraphic::DoubleGraphic (DoubleGraphic &g, const CharRect &region, bool copy=true)
	Construct a graphic that refers to the same region within a bit/attrmap. More...

	zxeco::DoubleGraphic::DoubleGraphic (DesktopInterface &desktop, const std::string &pngfile, const PNGConversionParms &parms={PNGConversionMode::ToNearestPlain, PNGConversionSubmode::None})
	Constructor from a .png file. More...

	zxeco::DoubleGraphic::DoubleGraphic (const DoubleGraphic &)=delete

DoubleGraphic &	zxeco::DoubleGraphic::operator= (const DoubleGraphic &)=delete

	zxeco::DoubleGraphic::DoubleGraphic (DoubleGraphic &&oth)

DoubleGraphic &	zxeco::DoubleGraphic::operator= (DoubleGraphic &&oth)

void	zxeco::DoubleGraphic::merge (const DoubleGraphic &oth, const CharCursor &pos, LinearGraphic::GraphOp mode=LinearGraphic::GraphOp::COPY)
	Merge both bitmap and attrmap of OTH at the given coordinates in MODE. More...

void	zxeco::DoubleGraphic::savePNG (DesktopInterface &desktop, const std::string &pngfile)
	Save the double graphic into a PNG file. More...

std::string	zxeco::DoubleGraphic::to_string (void) const
	Return a text with the info of the graphic. More...

RGBPalette::Index	zxeco::DoubleGraphic::DitheringSystem::Color::indexInPal (void) const noexcept

RGBColor	zxeco::DoubleGraphic::DitheringSystem::Color::rgbColor (void) const

RGBPalette::Index	zxeco::DoubleGraphic::DitheringSystem::Color::firstExtreme (void) const noexcept

RGBPalette::Index	zxeco::DoubleGraphic::DitheringSystem::Color::secondExtreme (void) const noexcept

DitherLevel	zxeco::DoubleGraphic::DitheringSystem::Color::ditherLevel (void) const noexcept

bool	zxeco::DoubleGraphic::DitheringSystem::Color::notDithered (void) const noexcept

bool	zxeco::DoubleGraphic::DitheringSystem::Color::equalExtremesOrder (const Color &oc) const noexcept

bool	zxeco::DoubleGraphic::DitheringSystem::Color::equalExtremesNotOrder (const Color &oc) const noexcept

bool	zxeco::DoubleGraphic::DitheringSystem::Color::equalExtremes (const Color &oc) const noexcept

Color	zxeco::DoubleGraphic::DitheringSystem::Color::makeCompatibleWith (const Color &oc) const noexcept

std::string	zxeco::DoubleGraphic::DitheringSystem::Color::to_string (void) const

	zxeco::DoubleGraphic::DitheringSystem::DitheringSystem (NumDithLevels nlvs)

	zxeco::DoubleGraphic::DitheringSystem::DitheringSystem (const DitheringSystem &)=delete

	zxeco::DoubleGraphic::DitheringSystem::DitheringSystem (DitheringSystem &&)=delete

DitheringSystem &	zxeco::DoubleGraphic::DitheringSystem::operator= (const DitheringSystem &)=delete

DitheringSystem &	zxeco::DoubleGraphic::DitheringSystem::operator= (DitheringSystem &&)=delete

constexpr NumDithLevels	zxeco::DoubleGraphic::DitheringSystem::numDithLevels (void) const noexcept

constexpr NumDithLevels	zxeco::DoubleGraphic::DitheringSystem::maxDithLevel (void) const noexcept

constexpr DitherLevel	zxeco::DoubleGraphic::DitheringSystem::inverseDithLevel (DitherLevel dl) const noexcept

constexpr RGBPalette::Size	zxeco::DoubleGraphic::DitheringSystem::numClusters (void) const noexcept

constexpr RGBPalette::Size	zxeco::DoubleGraphic::DitheringSystem::totalColors (void) const noexcept

double	zxeco::DoubleGraphic::DitheringSystem::dithLevDegree (DitherLevel dl) const

const RGBPalette &	zxeco::DoubleGraphic::DitheringSystem::ditheredPalette (void) const noexcept

Color	zxeco::DoubleGraphic::DitheringSystem::deployColor (const RGBColor &rgb) const

Color	zxeco::DoubleGraphic::DitheringSystem::deployColor (RGBPalette::Index palind) const

template<>
constexpr uint8_t	zxeco::LinearGraphic::doGraphOp< LinearGraphic::GraphOp::INV > (uint8_t b0, uint8_t b1) noexcept

template<>
constexpr uint8_t	zxeco::LinearGraphic::doGraphOp< LinearGraphic::GraphOp::OR > (uint8_t b0, uint8_t b1) noexcept

template<>
constexpr uint8_t	zxeco::LinearGraphic::doGraphOp< LinearGraphic::GraphOp::INVOR > (uint8_t b0, uint8_t b1) noexcept

template<>
constexpr uint8_t	zxeco::LinearGraphic::doGraphOp< LinearGraphic::GraphOp::AND > (uint8_t b0, uint8_t b1) noexcept

template<>
constexpr uint8_t	zxeco::LinearGraphic::doGraphOp< LinearGraphic::GraphOp::INVAND > (uint8_t b0, uint8_t b1) noexcept

template<>
constexpr uint8_t	zxeco::LinearGraphic::doGraphOp< LinearGraphic::GraphOp::XOR > (uint8_t b0, uint8_t b1) noexcept

template<>
constexpr uint8_t	zxeco::LinearGraphic::doGraphOp< LinearGraphic::GraphOp::INVXOR > (uint8_t b0, uint8_t b1) noexcept

Variables
constexpr PixelCoord	zxeco::kMaxPixelCoord = std::numeric_limits<PixelCoord>::max()
	Maximum value of a pixel coordinate. More...

constexpr CharCoord	zxeco::kMaxCharCoord = std::numeric_limits<CharCoord>::max()
	Maximum value of a char coordinate. More...

constexpr PixelDist	zxeco::kMaxPixelDist = std::numeric_limits<PixelDist>::max()
	Maximum value of a pixel distance. More...

constexpr CharDist	zxeco::kMaxCharDist = std::numeric_limits<CharDist>::max()
	Maximum value of a char distance. More...

constexpr IntDist	zxeco::kMinIntDist = std::numeric_limits<IntDist>::min()
	Minimum value of an int distance. More...

constexpr IntDist	zxeco::kMaxIntDist = std::numeric_limits<IntDist>::max()
	Maximum value of an int distance. More...

constexpr BorderCoord	zxeco::kMaxBorderCoord = std::numeric_limits<BorderCoord>::max()
	Maximum value of a border pixel coordinate. More...

constexpr BorderDist	zxeco::kMaxBorderDist = std::numeric_limits<BorderDist>::max()
	Maximum value of a border pixel distance. More...

static constexpr const char *	zxeco::CharCoordT::name = "CharC"
	Name of numeric type. More...

type	zxeco::CharCoordT::value
	To hold values of that type. More...

static constexpr const char *	zxeco::PixelCoordT::name = "PixC"
	Name of numeric type. More...

type	zxeco::PixelCoordT::value
	To hold values of that type. More...

static constexpr const char *	zxeco::CharDistT::name = "CharD"
	Name of numeric type. More...

type	zxeco::CharDistT::value
	To hold values of that type. More...

static constexpr const char *	zxeco::PixelDistT::name = "PixD"
	Name of numeric type. More...

type	zxeco::PixelDistT::value
	To hold values of that type. More...

static constexpr const char *	zxeco::IntDistT::name = "IntD"
	Name of numeric type. More...

type	zxeco::IntDistT::value
	To hold values of that type. More...

static constexpr const char *	zxeco::BorderCoordT::name = "BorderC"
	Name of numeric type. More...

type	zxeco::BorderCoordT::value
	To hold values of that type. More...

static constexpr const char *	zxeco::BorderDistT::name = "BorderD"
	Name of numeric type. More...

type	zxeco::BorderDistT::value
	To hold values of that type. More...

WidthType::type	zxeco::Cursor< WRES, HRES >::x
	Coordinate in width (horizontally). More...

HeightType::type	zxeco::Cursor< WRES, HRES >::y
	Coordinates in height (vertically). More...

WidthType::type	zxeco::Area< WRES, HRES >::width
	width of the area. More...

HeightType::type	zxeco::Area< WRES, HRES >::height
	height of the area. More...

cursor_type	zxeco::Rect< WRES, HRES >::corner
	Top-left corner. More...

area_type	zxeco::Rect< WRES, HRES >::area
	Width and height. More...

CharArea	zxeco::DoubleArea::chararea
	Char resolution. More...

PixArea	zxeco::DoubleArea::pixarea
	Pixel resolution. More...

CharRect	zxeco::DoubleRect::charrect
	Char resolution. More...

PixRect	zxeco::DoubleRect::pixrect
	Pixel resolution. More...

bool	zxeco::LinearGraphic::owner_

size_t	zxeco::LinearGraphic::s_

uint8_t zxeco::LinearGraphic::thebyte

uint8_t * zxeco::LinearGraphic::bytes

LinearGraphic * zxeco::LinearGraphic::other

size_t zxeco::LinearGraphic::firstoff

size_t zxeco::LinearGraphic::chunksize

size_t zxeco::LinearGraphic::gap

size_t zxeco::LinearGraphic::numchunks

struct {
LinearGraphic * zxeco::LinearGraphic::other

size_t zxeco::LinearGraphic::firstoff

size_t zxeco::LinearGraphic::chunksize

size_t zxeco::LinearGraphic::gap

size_t zxeco::LinearGraphic::numchunks

} zxeco::LinearGraphic::external

AreaType	zxeco::DimsGraphic< HEIGHTRESOL >::dims
	Dimensions of the graphic. More...

PNGConversionMode	zxeco::DoubleGraphic::PNGConversionParms::mode
	Mode for conversion. More...

PNGConversionSubmode	zxeco::DoubleGraphic::PNGConversionParms::submode
	Submode. More...

struct {
}	zxeco::DoubleGraphic::PNGConversionParms::tonearestplain
	Parms for ToNearestPlain mode.

NumDithLevels zxeco::DoubleGraphic::PNGConversionParms::numlevels
	Number of dithering levels. More...

struct {
NumDithLevels zxeco::DoubleGraphic::PNGConversionParms::numlevels
	Number of dithering levels. More...

}	zxeco::DoubleGraphic::PNGConversionParms::dither
	Parms for Dither and its submodes.

Bitmap	zxeco::DoubleGraphic::bitmap

Attrmap	zxeco::DoubleGraphic::attrmap

static constexpr NumDithLevels	zxeco::DoubleGraphic::DitheringSystem::kMinDiths = 3

static constexpr NumDithLevels	zxeco::DoubleGraphic::DitheringSystem::kMaxDiths = 101

static constexpr RGBPalette::Size	zxeco::DoubleGraphic::DitheringSystem::kNumPureColors

static constexpr RGBPalette::Size	zxeco::DoubleGraphic::DitheringSystem::kNumColorsButBright

static constexpr RGBPalette::Size	zxeco::DoubleGraphic::DitheringSystem::kClusterSizeButBright

static constexpr RGBPalette::Size	zxeco::DoubleGraphic::DitheringSystem::kClusterSize

friend	zxeco::DoubleGraphic::DitheringSystem::Color::DitheringSystem

Screen size constants
Width and height of the original ZX Spectrum screen. Notice that in the ZX ecosystem the screen can be opened with different dimensions.
constexpr PixelDist	zxeco::SCREENW = 256
	Width in pixels of the original zx screen. More...

constexpr PixelDist	zxeco::SCREENH = 192
	Height in pixels of the original zx screen. More...

constexpr BorderDist	zxeco::TOPBORDERH = 56
	Height in pixels of the original zx visible border in its top section. More...

constexpr BorderDist	zxeco::BOTTOMBORDERH = 56
	Height in pixels of the original zx visible border in its bottom section. More...

constexpr BorderDist	zxeco::LEFTBORDERW = 32
	Height in pixels of the original zx visible border in its left section. More...

constexpr BorderDist	zxeco::RIGHTBORDERW = 64
	Height in pixels of the original zx visible border in its right section. More...

constexpr CharDist	zxeco::SCREENCHARCOLS = 32
	Number of char columns in the screen. More...

constexpr CharDist	zxeco::SCREENCHARROWS = 24
	Number of char rows in the screen. More...

constexpr size_t	zxeco::BITMAPLEN = 6144
	Length in memory (bytes) of the original zx screen bitmap. More...

constexpr size_t	zxeco::ATTRMAPLEN = 768
	Length in memory (bytes) of the original zx screen attrmap. More...

constexpr size_t	zxeco::DISPLAYLEN = BITMAPLEN + ATTRMAPLEN
	Length in memory (bytes) of the original complete zx screen. More...

constexpr CharDist	zxeco::SCREENROWS = pixelDistToCharDist(SCREENH)
	Number of rows in the screen of the original ZX. More...

constexpr CharDist	zxeco::SCREENCOLS = pixelDistToCharDist(SCREENW)
	Number of columns in the screen of the original ZX. More...

	zxeco::DoubleArea::DoubleArea (const CharArea &area=CharArea::theEmpty())

	zxeco::DoubleArea::DoubleArea (const CharArea &carea, const PixArea &parea)

	zxeco::DoubleRect::DoubleRect (const CharRect &rect=CharRect::theEmpty())

	zxeco::DoubleRect::DoubleRect (const CharRect &crect, const PixRect &prect)

Typedef Documentation

◆ PixelCoord

using zxeco::PixelCoord = typedef uint16_t

#include <ZXGraphics.h>

Represent both x and y screen pix coordinates.

Definition at line 93 of file ZXGraphics.h.

◆ CharCoord

using zxeco::CharCoord = typedef uint16_t

#include <ZXGraphics.h>

Represent both x and y screen char coordinates.

Definition at line 94 of file ZXGraphics.h.

◆ PixelDist

using zxeco::PixelDist = typedef uint16_t

#include <ZXGraphics.h>

A distance measured in screen pixels.

Definition at line 96 of file ZXGraphics.h.

◆ CharDist

using zxeco::CharDist = typedef uint16_t

#include <ZXGraphics.h>

A distance meadured in screen chars.

Definition at line 97 of file ZXGraphics.h.

◆ IntDist

using zxeco::IntDist = typedef int16_t

#include <ZXGraphics.h>

Positive and negative distances on screen.

Definition at line 99 of file ZXGraphics.h.

◆ BorderCoord

using zxeco::BorderCoord = typedef int16_t

#include <ZXGraphics.h>

Represent both x and y pix coords in border.

Definition at line 101 of file ZXGraphics.h.

◆ BorderDist

using zxeco::BorderDist = typedef uint16_t

#include <ZXGraphics.h>

A distance measured in pixels in the border.

Definition at line 102 of file ZXGraphics.h.

◆ type [1/7]

using zxeco::CharCoordT::type = CharCoord

Numerical type corresponding to this class.

Definition at line 269 of file ZXGraphics.h.

◆ type [2/7]

using zxeco::PixelCoordT::type = PixelCoord

Numerical type corresponding to this class.

Definition at line 279 of file ZXGraphics.h.

◆ type [3/7]

using zxeco::CharDistT::type = CharDist

Numerical type corresponding to this class.

Definition at line 289 of file ZXGraphics.h.

◆ coord_typeT [1/3]

using zxeco::CharDistT::coord_typeT = CharCoordT

Corresponding coord type trait.

Definition at line 291 of file ZXGraphics.h.

◆ type [4/7]

using zxeco::PixelDistT::type = PixelDist

Numerical type corresponding to this class.

Definition at line 301 of file ZXGraphics.h.

◆ coord_typeT [2/3]

using zxeco::PixelDistT::coord_typeT = PixelCoordT

Corresponding coord type trait.

Definition at line 303 of file ZXGraphics.h.

◆ type [5/7]

using zxeco::IntDistT::type = IntDist

Numerical type corresponding to this class.

Definition at line 314 of file ZXGraphics.h.

◆ type [6/7]

using zxeco::BorderCoordT::type = BorderCoord

Numerical type corresponding to this class.

Definition at line 324 of file ZXGraphics.h.

◆ type [7/7]

using zxeco::BorderDistT::type = BorderDist

Numerical type corresponding to this class.

Definition at line 334 of file ZXGraphics.h.

◆ coord_typeT [3/3]

using zxeco::BorderDistT::coord_typeT = BorderCoordT

Corresponding coord type trait.

Definition at line 336 of file ZXGraphics.h.

◆ WidthType [1/2]

template<typename WRES , typename HRES >

using zxeco::Cursor< WRES, HRES >::WidthType = WRES

Type used for the width dimension.

Definition at line 362 of file ZXGraphics.h.

◆ HeightType [1/2]

template<typename WRES , typename HRES >

using zxeco::Cursor< WRES, HRES >::HeightType = HRES

Type used for the height dimension.

Definition at line 363 of file ZXGraphics.h.

◆ CharCursor

using zxeco::CharCursor = typedef Cursor<CharCoordT,CharCoordT>

#include <ZXGraphics.h>

Shortcut for this kind of cursor.

Definition at line 467 of file ZXGraphics.h.

◆ PixCursor

using zxeco::PixCursor = typedef Cursor<PixelCoordT,PixelCoordT>

#include <ZXGraphics.h>

Shortcut for this kind of cursor.

Definition at line 470 of file ZXGraphics.h.

◆ CharPixCursor

using zxeco::CharPixCursor = typedef Cursor<CharCoordT,PixelCoordT>

#include <ZXGraphics.h>

Shortcut for this kind of cursor.

Definition at line 473 of file ZXGraphics.h.

◆ BorderCursor

using zxeco::BorderCursor = typedef Cursor<BorderCoordT,BorderCoordT>

#include <ZXGraphics.h>

Shortcut for this kind of cursor.

Definition at line 476 of file ZXGraphics.h.

◆ WidthType [2/2]

template<typename WRES , typename HRES >

using zxeco::Area< WRES, HRES >::WidthType = WRES

Type used for the width dimension.

Definition at line 507 of file ZXGraphics.h.

◆ HeightType [2/2]

template<typename WRES , typename HRES >

using zxeco::Area< WRES, HRES >::HeightType = HRES

Type used for the height dimension.

Definition at line 508 of file ZXGraphics.h.

◆ CursorType [1/2]

template<typename WRES , typename HRES >

using zxeco::Area< WRES, HRES >::CursorType = Cursor<typename WRES::coord_typeT, typename HRES::coord_typeT>

Cursor.

Definition at line 509 of file ZXGraphics.h.

◆ CharArea

using zxeco::CharArea = typedef Area<CharDistT,CharDistT>

#include <ZXGraphics.h>

Shortcut for this kind of area.

Definition at line 604 of file ZXGraphics.h.

◆ PixArea

using zxeco::PixArea = typedef Area<PixelDistT,PixelDistT>

#include <ZXGraphics.h>

Shortcut for this kind of area.

Definition at line 607 of file ZXGraphics.h.

◆ CharPixArea

using zxeco::CharPixArea = typedef Area<CharDistT,PixelDistT>

#include <ZXGraphics.h>

Shortcut for this kind of area.

Definition at line 610 of file ZXGraphics.h.

◆ BorderArea

using zxeco::BorderArea = typedef Area<BorderDistT,BorderDistT>

#include <ZXGraphics.h>

Shortcut for this kind of area.

Definition at line 613 of file ZXGraphics.h.

◆ cursor_type

template<typename WRES , typename HRES >

using zxeco::Rect< WRES, HRES >::cursor_type = Cursor<typename WRES::coord_typeT, typename HRES::coord_typeT>

Definition at line 645 of file ZXGraphics.h.

◆ area_type

template<typename WRES , typename HRES >

using zxeco::Rect< WRES, HRES >::area_type = Area<WRES,HRES>

Definition at line 647 of file ZXGraphics.h.

◆ CharRect

using zxeco::CharRect = typedef Rect<CharDistT,CharDistT>

#include <ZXGraphics.h>

Shortcut for this kind of rectangle.

Definition at line 734 of file ZXGraphics.h.

◆ PixRect

using zxeco::PixRect = typedef Rect<PixelDistT,PixelDistT>

#include <ZXGraphics.h>

Shortcut for this kind of rectangle.

Definition at line 737 of file ZXGraphics.h.

◆ CharPixRect

using zxeco::CharPixRect = typedef Rect<CharDistT,PixelDistT>

#include <ZXGraphics.h>

Shortcut for this kind of rectangle.

Definition at line 740 of file ZXGraphics.h.

◆ BorderRect

using zxeco::BorderRect = typedef Rect<BorderDistT,BorderDistT>

#include <ZXGraphics.h>

Shortcut for this kind of rectangle.

Definition at line 743 of file ZXGraphics.h.

◆ CursorType [2/2]

template<typename HEIGHTRESOL >

using zxeco::DimsGraphic< HEIGHTRESOL >::CursorType = Cursor<CharCoordT,typename HEIGHTRESOL::coord_typeT>

Definition at line 1012 of file ZXGraphics.h.

◆ AreaType

template<typename HEIGHTRESOL >

using zxeco::DimsGraphic< HEIGHTRESOL >::AreaType = Area<CharDistT,HEIGHTRESOL>

Definition at line 1013 of file ZXGraphics.h.

◆ RectType

template<typename HEIGHTRESOL >

using zxeco::DimsGraphic< HEIGHTRESOL >::RectType = Rect<CharDistT,HEIGHTRESOL>

Definition at line 1014 of file ZXGraphics.h.

◆ BaseGr [1/2]

using zxeco::Bitmap::BaseGr = DimsGraphic<PixelDistT>

Definition at line 1154 of file ZXGraphics.h.

◆ BaseGr [2/2]

using zxeco::Attrmap::BaseGr = DimsGraphic<CharDistT>

Definition at line 1224 of file ZXGraphics.h.

◆ NumDithLevels

using zxeco::DoubleGraphic::NumDithLevels = uint8_t

Type for storing number of dithering levels.

Definition at line 1271 of file ZXGraphics.h.

◆ DitherLevel

using zxeco::DoubleGraphic::DitheringSystem::DitherLevel = NumDithLevels

Definition at line 1383 of file ZXGraphics.h.

Enumeration Type Documentation

◆ GraphOp

enum class zxeco::LinearGraphic::GraphOp : unsigned char

strong

Possible operations on Graphics.

Enumerator
COPY	put the graphic on the screen (substitution)
INV	like COPY but with the graphic bits inverted first
OR	OR the graphic and the screen content.
INVOR	like OR but first invert the graphic bits
AND	AND the graphic and the screen content.
INVAND	like AND but first inverts the graphic bits
XOR	XOR the graphic and the screen content.
INVXOR	like XOR but with the graphic bits inverted first

Definition at line 841 of file ZXGraphics.h.

◆ PNGConversionMode

enum class zxeco::DoubleGraphic::PNGConversionMode

strong

Modes of conversion of PNG images into DoubleGraphic.

Enumerator
ToNearestPlain	The algorithm in http://jafma.net/software/zxscreen/
Dither	Use more colours thrugh dithering.

Definition at line 1256 of file ZXGraphics.h.

◆ PNGConversionSubmode

enum class zxeco::DoubleGraphic::PNGConversionSubmode

strong

Submode of conversion of PNG images into DoubleGraphic.

Enumerator
None	No submode.
FixedPattern	Fixed pattern dithr
Noise	Noise dithering.

Definition at line 1264 of file ZXGraphics.h.

Function Documentation

◆ charOfPixelX()

constexpr CharCoord zxeco::charOfPixelX ( PixelCoord pc )

constexprnoexcept

#include <ZXGraphics.h>

Conversion from an x-PixelCoord to CharCoord.

Return the x coord of the char where this pixel (x coordinate) is.

Definition at line 134 of file ZXGraphics.h.

◆ charOfPixelY()

constexpr CharCoord zxeco::charOfPixelY ( PixelCoord pc )

constexprnoexcept

#include <ZXGraphics.h>

Conversion from an y-PixelCoord to CharCoord.

Return the y coord of the char where this pixel (y coordinate) is.

Definition at line 139 of file ZXGraphics.h.

◆ firstPixelInCharX()

constexpr PixelCoord zxeco::firstPixelInCharX ( PixelCoord pc )

constexprnoexcept

#include <ZXGraphics.h>

Get the PixelCoord of 1st pixel in the character of this x-PixelCoord.

Return the x coord of the 1st pixel of the same char of this pixel (considered as an x coordinate).

Definition at line 145 of file ZXGraphics.h.

◆ firstPixelInCharY()

constexpr PixelCoord zxeco::firstPixelInCharY ( PixelCoord pc )

constexprnoexcept

#include <ZXGraphics.h>

Get the PixelCoord of 1st pixel in the character of this y-PixelCoord.

Return the y coord of the 1st pixel of the same char of this pixel (considered as a y coordinate).

Definition at line 151 of file ZXGraphics.h.

◆ bitOfPixelX()

constexpr unsigned char zxeco::bitOfPixelX ( PixelCoord pc )

constexprnoexcept

#include <ZXGraphics.h>

Get the bit position of the pixel of this x-PixelCoord.

Return the bit corresponding to this coord (x coordinate), being 7 for the left-most bit of the corresponding char coordinate and 0 for the right-most one.

Definition at line 158 of file ZXGraphics.h.

◆ pixelOfCharX()

constexpr PixelCoord zxeco::pixelOfCharX ( CharCoord cc )

constexprnoexcept

#include <ZXGraphics.h>

Conversion from an x-CharCoord to PixelCoord.

Return the x coord of the 1st pixel of the char whose x coordinate is this.

Definition at line 167 of file ZXGraphics.h.

◆ pixelOfCharY()

constexpr PixelCoord zxeco::pixelOfCharY ( CharCoord cc )

constexprnoexcept

#include <ZXGraphics.h>

Conversion from a y-CharCoord to PixelCoord.

Return the y coord of the 1st pixel of the char whose y coordinate is this.

Definition at line 173 of file ZXGraphics.h.

◆ charDistToPixelDist()

constexpr PixelDist zxeco::charDistToPixelDist ( CharDist pc )

constexprnoexcept

#include <ZXGraphics.h>

Conversion from CharDist to PixelDist.

Count 8 pixels per character cell and thus the result is greater than the numeric value of PC.

Definition at line 215 of file ZXGraphics.h.

◆ pixelDistToCharDist()

constexpr CharDist zxeco::pixelDistToCharDist	(	PixelDist	cc,
		bool	toceil = `true`
	)

constexprnoexcept

#include <ZXGraphics.h>

Conversion from PixelDist to CharDist.

Count 8 pixels per character cell, and thus the result is smaller than the numerical value of CC. If TOCEIL, count one character at least even when there are less than 8 pixels.

Definition at line 224 of file ZXGraphics.h.

◆ theZero()

template<typename WRES , typename HRES >

static const Cursor & zxeco::Cursor< WRES, HRES >::theZero ( void )

inlinestaticnoexcept

#include <ZXGraphics.h>

< Return a reference to an inmutable zero cursorof this type.

Definition at line 368 of file ZXGraphics.h.

◆ max()

template<typename WRES , typename HRES >

static Cursor zxeco::Cursor< WRES, HRES >::max	(	const Cursor< WRES, HRES > &	c0,
		const Cursor< WRES, HRES > &	c1
	)

inlinestaticnoexcept

#include <ZXGraphics.h>

< Return a copy of the one of C0, C1 that is more to the right and below.

Definition at line 372 of file ZXGraphics.h.

◆ Cursor() [1/2]

template<typename WRES , typename HRES >

zxeco::Cursor< WRES, HRES >::Cursor	(	typename WidthType::type	xc,
		typename HeightType::type	yc
	)

inline

#include <ZXGraphics.h>

Constructor, from the numerical coord types.

No default values for preventing common errors of promotion of numbers to this type (without being so strict as by defining it as explicit).

Definition at line 377 of file ZXGraphics.h.

◆ Cursor() [2/2]

template<typename WRES , typename HRES >

zxeco::Cursor< WRES, HRES >::Cursor	(	WidthType	xc,
		HeightType	yc
	)

inline

#include <ZXGraphics.h>

Constructor from the trait coord types.

Definition at line 382 of file ZXGraphics.h.

◆ newRow()

template<typename WRES , typename HRES >

void zxeco::Cursor< WRES, HRES >::newRow ( void )

inlinenoexcept

#include <ZXGraphics.h>

Go down one row resetting x (y <- y + 1 & x <- 0).

Definition at line 386 of file ZXGraphics.h.

◆ newCol()

template<typename WRES , typename HRES >

void zxeco::Cursor< WRES, HRES >::newCol ( void )

inlinenoexcept

#include <ZXGraphics.h>

Go right one column (x <- x + 1).

Definition at line 389 of file ZXGraphics.h.

◆ incRow()

template<typename WRES , typename HRES >

void zxeco::Cursor< WRES, HRES >::incRow ( void )

inlinenoexcept

#include <ZXGraphics.h>

Go down one row without resetting x.

Definition at line 392 of file ZXGraphics.h.

◆ zero()

template<typename WRES , typename HRES >

bool zxeco::Cursor< WRES, HRES >::zero ( void ) const

inlinenoexcept

#include <ZXGraphics.h>

Return TRUE if the cursor is placed at (0,0). *‍/.

Definition at line 395 of file ZXGraphics.h.

◆ before()

template<typename WRES , typename HRES >

bool zxeco::Cursor< WRES, HRES >::before ( const Cursor< WRES, HRES > & oth ) const

inlinenoexcept

#include <ZXGraphics.h>

< Return TRUE if THIS is placed before OTH in the plane (linearly).

< If both are equal, return FALSE.

Definition at line 398 of file ZXGraphics.h.

◆ rightBelow()

template<typename WRES , typename HRES >

bool zxeco::Cursor< WRES, HRES >::rightBelow ( const Cursor< WRES, HRES > & oth ) const

inlinenoexcept

#include <ZXGraphics.h>

< Return TRUE if THIS is placed to the right and below of OTH.

< If it coincides in any of the coords, return TRUE.

Definition at line 403 of file ZXGraphics.h.

◆ xDiff()

template<typename WRES , typename HRES >

IntDist zxeco::Cursor< WRES, HRES >::xDiff ( const Cursor< WRES, HRES > & oth ) const

inlinenoexcept

#include <ZXGraphics.h>

< Return the signed distance in X from OTH to THIS.

Definition at line 408 of file ZXGraphics.h.

◆ yDiff()

template<typename WRES , typename HRES >

IntDist zxeco::Cursor< WRES, HRES >::yDiff ( const Cursor< WRES, HRES > & oth ) const

inlinenoexcept

#include <ZXGraphics.h>

< Return the signed distance in Y from OTH to THIS.

Definition at line 412 of file ZXGraphics.h.

◆ addDiff()

template<typename WRES , typename HRES >

void zxeco::Cursor< WRES, HRES >::addDiff	(	IntDist	xdiff,
		IntDist	ydiff
	)

inlinenoexcept

#include <ZXGraphics.h>

< Add the given signed distances to both coordinates.

Definition at line 416 of file ZXGraphics.h.

◆ operator==() [1/3]

template<typename WRES , typename HRES >

bool zxeco::Cursor< WRES, HRES >::operator== ( const Cursor< WRES, HRES > & oth ) const

inlinenoexcept

#include <ZXGraphics.h>

< Return TRUE if both cursors are placed at the same place.

Definition at line 423 of file ZXGraphics.h.

◆ operator!=() [1/3]

template<typename WRES , typename HRES >

bool zxeco::Cursor< WRES, HRES >::operator!= ( const Cursor< WRES, HRES > & oth ) const

inlinenoexcept

#include <ZXGraphics.h>

< Unequality.

Definition at line 427 of file ZXGraphics.h.

◆ operator+() [1/2]

template<typename WRES , typename HRES >

Cursor zxeco::Cursor< WRES, HRES >::operator+ ( const Cursor< WRES, HRES > & oth ) const

inline

#include <ZXGraphics.h>

< Return the sum of both cursors.

Definition at line 431 of file ZXGraphics.h.

◆ operator+=() [1/2]

template<typename WRES , typename HRES >

Cursor & zxeco::Cursor< WRES, HRES >::operator+= ( const Cursor< WRES, HRES > & oth )

inline

#include <ZXGraphics.h>

Make the sum and return the result.

Definition at line 437 of file ZXGraphics.h.

◆ operator-() [1/2]

template<typename WRES , typename HRES >

Cursor zxeco::Cursor< WRES, HRES >::operator- ( const Cursor< WRES, HRES > & oth ) const

inline

#include <ZXGraphics.h>

< Return the cursor THIS relative to OTH, or throw if result is negative.

Definition at line 440 of file ZXGraphics.h.

◆ operator-=() [1/2]

template<typename WRES , typename HRES >

Cursor & zxeco::Cursor< WRES, HRES >::operator-= ( const Cursor< WRES, HRES > & oth )

inline

#include <ZXGraphics.h>

Make the substraction and return the result.

Definition at line 448 of file ZXGraphics.h.

◆ to_string() [1/9]

template<typename WRES , typename HRES >

std::string zxeco::Cursor< WRES, HRES >::to_string ( bool withtype = true ) const

inline

#include <ZXGraphics.h>

< Return a string with the textual information of the area.

Definition at line 451 of file ZXGraphics.h.

◆ getPixCursor() [1/2]

PixCursor zxeco::getPixCursor ( const CharCursor & cc )

inline

#include <ZXGraphics.h>

Convert a char cursor to a pix cursor placed at the top-left of the former.

Definition at line 481 of file ZXGraphics.h.

◆ getPixCursor() [2/2]

PixCursor zxeco::getPixCursor ( const CharPixCursor & cc )

inline

#include <ZXGraphics.h>

Convert a char-pix cursor to a pix cursor placed at the top-left of former.

Definition at line 485 of file ZXGraphics.h.

◆ getCharPixCursor()

CharPixCursor zxeco::getCharPixCursor ( const CharCursor & cc )

inline

#include <ZXGraphics.h>

Convert a char cursor to a char-pix cursor placed at the top of the former.

Definition at line 489 of file ZXGraphics.h.

◆ theEmpty() [1/2]

template<typename WRES , typename HRES >

static const Area & zxeco::Area< WRES, HRES >::theEmpty ( void )

inlinestaticnoexcept

#include <ZXGraphics.h>

Return a reference to an inmutable empty area of this type.

Definition at line 515 of file ZXGraphics.h.

◆ Area() [1/3]

template<typename WRES , typename HRES >

zxeco::Area< WRES, HRES >::Area	(	typename WidthType::type	w,
		typename HeightType::type	h
	)

inline

#include <ZXGraphics.h>

Default constructor, from the numerical dist types.

No default values for preventing common errors of promotion of numbers to this type (without being so strict as by defining it as explicit).

Definition at line 520 of file ZXGraphics.h.

◆ Area() [2/3]

template<typename WRES , typename HRES >

zxeco::Area< WRES, HRES >::Area	(	WidthType	w,
		HeightType	h
	)

inline

#include <ZXGraphics.h>

Constructor from the trait dist types.

Definition at line 525 of file ZXGraphics.h.

◆ Area() [3/3]

template<typename WRES , typename HRES >

zxeco::Area< WRES, HRES >::Area	(	const CursorType &	c0,
		const CursorType &	c1
	)

inline

#include <ZXGraphics.h>

Constructor of the area within C0 (top-left) and C1 (bottom-right).

Both are considered included in the area. Throw if the corners are invalid.

Definition at line 531 of file ZXGraphics.h.

◆ empty() [1/2]

template<typename WRES , typename HRES >

bool zxeco::Area< WRES, HRES >::empty ( void ) const

inlinenoexcept

#include <ZXGraphics.h>

Return TRUE if the area is empty.

Definition at line 535 of file ZXGraphics.h.

◆ area()

template<typename WRES , typename HRES >

size_t zxeco::Area< WRES, HRES >::area ( void ) const

inlinenoexcept

#include <ZXGraphics.h>

< Return the number of cells in the area.

Definition at line 538 of file ZXGraphics.h.

◆ containedInto()

template<typename WRES , typename HRES >

bool zxeco::Area< WRES, HRES >::containedInto ( const Area< WRES, HRES > & oth ) const

inlinenoexcept

#include <ZXGraphics.h>

< Return TRUE if this area can be contained into OTH or if they are equal

Definition at line 542 of file ZXGraphics.h.

◆ operator+() [2/2]

template<typename WRES , typename HRES >

Area zxeco::Area< WRES, HRES >::operator+ ( const Area< WRES, HRES > & oth ) const

inlinenoexcept

#include <ZXGraphics.h>

< Add width and height of OTH to THIS.

Definition at line 546 of file ZXGraphics.h.

◆ operator+=() [2/2]

template<typename WRES , typename HRES >

Area & zxeco::Area< WRES, HRES >::operator+= ( const Area< WRES, HRES > & oth )

inlinenoexcept

#include <ZXGraphics.h>

< Add to THIS the width and height of OTH.

Definition at line 552 of file ZXGraphics.h.

◆ operator-() [2/2]

template<typename WRES , typename HRES >

Area zxeco::Area< WRES, HRES >::operator- ( const Area< WRES, HRES > & oth ) const

inline

#include <ZXGraphics.h>

< Substract OTH dimensions from THIS dims and return the result, or throw

Definition at line 556 of file ZXGraphics.h.

◆ operator-=() [2/2]

template<typename WRES , typename HRES >

Area & zxeco::Area< WRES, HRES >::operator-= ( const Area< WRES, HRES > & oth )

inline

#include <ZXGraphics.h>

Substract OTH from THIS and return THIS. Throw if error.

Definition at line 565 of file ZXGraphics.h.

◆ operator*()

template<typename WRES , typename HRES >

Area zxeco::Area< WRES, HRES >::operator* ( const Area< WRES, HRES > & oth ) const

inline

#include <ZXGraphics.h>

< Intersect OTH dimensions to THIS dims and return the result.

Definition at line 570 of file ZXGraphics.h.

◆ operator*=()

template<typename WRES , typename HRES >

Area & zxeco::Area< WRES, HRES >::operator*= ( const Area< WRES, HRES > & oth )

inline

#include <ZXGraphics.h>

Intersect OTH to THIS and return THIS.

Definition at line 575 of file ZXGraphics.h.

◆ operator==() [2/3]

template<typename WRES , typename HRES >

bool zxeco::Area< WRES, HRES >::operator== ( const Area< WRES, HRES > & oth ) const

inlinenoexcept

#include <ZXGraphics.h>

< Equality.

Definition at line 579 of file ZXGraphics.h.

◆ operator!=() [2/3]

template<typename WRES , typename HRES >

bool zxeco::Area< WRES, HRES >::operator!= ( const Area< WRES, HRES > & oth ) const

inlinenoexcept

#include <ZXGraphics.h>

< Unequality.

Definition at line 583 of file ZXGraphics.h.

◆ to_string() [2/9]

template<typename WRES , typename HRES >

std::string zxeco::Area< WRES, HRES >::to_string ( bool withtype = true ) const

inline

#include <ZXGraphics.h>

< Return a string with the textual information of the area.

Definition at line 587 of file ZXGraphics.h.

◆ getPixArea() [1/2]

PixArea zxeco::getPixArea ( const CharArea & cc )

inline

#include <ZXGraphics.h>

Convert a char area to a pix area covering the same region on screen.

Definition at line 618 of file ZXGraphics.h.

◆ getPixArea() [2/2]

PixArea zxeco::getPixArea ( const CharPixArea & cc )

inline

#include <ZXGraphics.h>

Convert a char-pix area to a pix area covering the same region on screen.

Definition at line 623 of file ZXGraphics.h.

◆ getCharPixArea()

CharPixArea zxeco::getCharPixArea ( const CharArea & cc )

inline

#include <ZXGraphics.h>

Convert a char area to a char-pix area covering the same region on screen.

Definition at line 627 of file ZXGraphics.h.

◆ theEmpty() [2/2]

template<typename WRES , typename HRES >

static const Rect & zxeco::Rect< WRES, HRES >::theEmpty ( void )

inlinestaticnoexcept

#include <ZXGraphics.h>

Return a reference to an inmutable empty rectangle of this type.

Definition at line 652 of file ZXGraphics.h.

◆ Rect()

template<typename WRES , typename HRES >

zxeco::Rect< WRES, HRES >::Rect	(	const cursor_type &	c = `cursor_type{0,0}`,
		const area_type &	a = `area_type{0,0}`
	)

inline

#include <ZXGraphics.h>

Default constructor: empty rectangle.

Definition at line 658 of file ZXGraphics.h.

◆ empty() [2/2]

template<typename WRES , typename HRES >

bool zxeco::Rect< WRES, HRES >::empty ( void ) const

inlinenoexcept

#include <ZXGraphics.h>

Return TRUE if the rectangle area is empty.

Definition at line 662 of file ZXGraphics.h.

◆ contains()

template<typename WRES , typename HRES >

bool zxeco::Rect< WRES, HRES >::contains ( const cursor_type & cur ) const

noexcept

#include <ZXGraphics.h>

Return TRUE if CUR is inside the rectangle.

Definition at line 1557 of file ZXGraphics.h.

◆ bottomRight()

template<typename WRES , typename HRES >

cursor_type zxeco::Rect< WRES, HRES >::bottomRight ( void ) const

inlinenoexcept

#include <ZXGraphics.h>

< Return the coordinates of the bottom-right extreme within the rectangle

Definition at line 668 of file ZXGraphics.h.

◆ applyConstrainedDiffs()

template<typename WRES , typename HRES >

bool zxeco::Rect< WRES, HRES >::applyConstrainedDiffs	(	IntDist &	xdiff,
		IntDist &	ydiff,
		const Rect< WRES, HRES > &	oth
	)

noexcept

#include <ZXGraphics.h>

Apply the given increments to the corner of THIS, keeping it within OTH.

Return TRUE if the corner has changed. XDIFF and YDIFF are changed to contain the actual changes made under the constraints.

Definition at line 1564 of file ZXGraphics.h.

◆ compose()

template<typename WRES , typename HRES >

Rect zxeco::Rect< WRES, HRES >::compose ( const Rect< WRES, HRES > & reloth ) const

inline

#include <ZXGraphics.h>

< Return the RELOTH region of THIS as a rectangle.

< This serves to define rectangles that are relative to others (contained into others), like RELOTH, that is relative to THIS, and to get the absolute rectangle equivalent to them. This method does not detect any error in the definition of the rectangles, nor if RELOTH is not contained into THIS.

Definition at line 681 of file ZXGraphics.h.

◆ subRect()

template<typename WRES , typename HRES >

Rect zxeco::Rect< WRES, HRES >::subRect ( const cursor_type & reltopleft ) const

inline

#include <ZXGraphics.h>

< Return the absolute sub-rectangle that starts at RELTOPLEFT within this

Definition at line 691 of file ZXGraphics.h.

◆ intersect()

template<typename WRES , typename HRES >

Rect< WRES, HRES > zxeco::Rect< WRES, HRES >::intersect ( const Rect< WRES, HRES > & oth ) const

noexcept

#include <ZXGraphics.h>

Return the rectangle resulting from the intersection of this and OTH.

Return an empty rectangle placed at (0,0) if no such intersection exists.

Definition at line 1593 of file ZXGraphics.h.

◆ align_area()

template<typename WRES , typename HRES >

Rect< WRES, HRES > zxeco::Rect< WRES, HRES >::align_area	(	const area_type &	areaneeded,
		char	horalign,
		char	vertalign
	)		const

#include <ZXGraphics.h>

Return the portion of this rectangle that contains AREANEEDED aligned.

Throw if AREANEEDED cannot enter within this rectangle. The rectangle returned corner is in the same absolute reference system as this rectangle, not relative to it.

Parameters

horalign	must be one of 'C' (center), 'R' (right) or 'L' (left).
vertalign	must be one of 'M' (middle), 'B' (bottom) or 'T' (top).

Definition at line 1628 of file ZXGraphics.h.

◆ operator==() [3/3]

template<typename WRES , typename HRES >

bool zxeco::Rect< WRES, HRES >::operator== ( const Rect< WRES, HRES > & oth ) const

inlinenoexcept

#include <ZXGraphics.h>

< Equality.

Definition at line 712 of file ZXGraphics.h.

◆ operator!=() [3/3]

template<typename WRES , typename HRES >

bool zxeco::Rect< WRES, HRES >::operator!= ( const Rect< WRES, HRES > & oth ) const

inlinenoexcept

#include <ZXGraphics.h>

< Unequality.

Definition at line 716 of file ZXGraphics.h.

◆ to_string() [3/9]

template<typename WRES , typename HRES >

std::string zxeco::Rect< WRES, HRES >::to_string ( bool withtype = true ) const

inline

#include <ZXGraphics.h>

< Return a string with the textual information of the rectangle.

Definition at line 720 of file ZXGraphics.h.

◆ getPixRect() [1/2]

PixRect zxeco::getPixRect ( const CharRect & cc )

inline

#include <ZXGraphics.h>

Convert a char rect to a pix rect representing the same region on screen.

Definition at line 748 of file ZXGraphics.h.

◆ getPixRect() [2/2]

PixRect zxeco::getPixRect ( const CharPixRect & cc )

inline

#include <ZXGraphics.h>

Convert a char-pix rect to a pix rect representing the same region.

Definition at line 752 of file ZXGraphics.h.

◆ getCharPixRect()

CharPixRect zxeco::getCharPixRect ( const CharRect & cc )

inline

#include <ZXGraphics.h>

Convert a char rect to a char-pix rect representing the same region.

Definition at line 756 of file ZXGraphics.h.

◆ DoubleArea() [1/2]

zxeco::DoubleArea::DoubleArea ( const CharArea & area = CharArea::theEmpty() )

inline

#include <ZXGraphics.h>

Definition at line 778 of file ZXGraphics.h.

◆ DoubleArea() [2/2]

zxeco::DoubleArea::DoubleArea	(	const CharArea &	carea,
		const PixArea &	parea
	)

inline

#include <ZXGraphics.h>

Definition at line 783 of file ZXGraphics.h.

◆ to_string() [4/9]

std::string zxeco::DoubleArea::to_string ( void ) const

inline

#include <ZXGraphics.h>

Definition at line 791 of file ZXGraphics.h.

◆ DoubleRect() [1/2]

zxeco::DoubleRect::DoubleRect ( const CharRect & rect = CharRect::theEmpty() )

inline

#include <ZXGraphics.h>

Definition at line 808 of file ZXGraphics.h.

◆ DoubleRect() [2/2]

zxeco::DoubleRect::DoubleRect	(	const CharRect &	crect,
		const PixRect &	prect
	)

inline

#include <ZXGraphics.h>

Definition at line 813 of file ZXGraphics.h.

◆ to_string() [5/9]

std::string zxeco::DoubleRect::to_string ( void ) const

inline

#include <ZXGraphics.h>

Definition at line 820 of file ZXGraphics.h.

◆ LinearGraphic() [1/3]

zxeco::LinearGraphic::LinearGraphic ( size_t s )

#include <ZXGraphics.h>

Construct an empty graphic of the given size, yet to be filled.

S can be 0.

◆ LinearGraphic() [2/3]

zxeco::LinearGraphic::LinearGraphic	(	uint8_t *	bs,
		size_t	s
	)

#include <ZXGraphics.h>

Construct a graphic that is held externally (NO OWNERSHIP to this).

S must be > 0.

◆ LinearGraphic() [3/3]

zxeco::LinearGraphic::LinearGraphic	(	LinearGraphic &	oth,
		size_t	firstoff,
		size_t	chunksize,
		size_t	gap,
		size_t	numchunks
	)

#include <ZXGraphics.h>

Construct a graphic referring to part of another one (no ownership).

This graphic will refer in all operations to a part of OTH that begins at FIRSTOFF (in OTH) and has a number NUMCHUNKS of contiguous chunks of CHUNKSIZE (>0) separated by GAP bytes from each other. OTH must outlive this object and cannot be onebyte.

Note: A LinearGraphic may be created this way referring to a LinearGraphic that was also created this way, and so on. Notice, however, that the longer the chain, the slower some operations.

◆ external()

bool zxeco::LinearGraphic::external ( void ) const

inlinenoexcept

#include <ZXGraphics.h>

Whether the object refers to part of another linear graphic.

Definition at line 900 of file ZXGraphics.h.

◆ owner()

bool zxeco::LinearGraphic::owner ( void ) const

inlinenoexcept

#include <ZXGraphics.h>

Whether the object owns the graphical data.

Return TRUE if this object owns the graphical data and thus will delete them at destruction.

Definition at line 903 of file ZXGraphics.h.

◆ size()

size_t zxeco::LinearGraphic::size ( void ) const

inlinenoexcept

#include <ZXGraphics.h>

Size in memory, in bytes.

Return the size in bytes of the graphic content, even when ONEBYTE == TRUE (that is, in that case the size will not be necessarily 1) or when it refers to an external linear graphic (in that case the size is the sum of bytes accessible from this object).

Definition at line 907 of file ZXGraphics.h.

◆ oneByte()

bool zxeco::LinearGraphic::oneByte ( void ) const

inlinenoexcept

#include <ZXGraphics.h>

Return TRUE if the graphic content is compressed into one byte.

Definition at line 913 of file ZXGraphics.h.

◆ setByte() [1/2]

void zxeco::LinearGraphic::setByte	(	size_t	offset,
		uint8_t	b
	)

#include <ZXGraphics.h>

Change the byte at the given offset inside the data.

If the graphic is onebyte or the offset is invalid, throw an exception.

◆ setByteUnsafe()

void zxeco::LinearGraphic::setByteUnsafe	(	size_t	offset,
		uint8_t	b
	)

noexcept

#include <ZXGraphics.h>

Change the byte at the given offset without checking anything.

If the graphic is onebyte, do nothing.

◆ setAllBytes()

void zxeco::LinearGraphic::setAllBytes ( uint8_t b )

noexcept

#include <ZXGraphics.h>

Set all bytes of the graphic to the given value.

Works correctly either if this graphic is onebyte-filled or not.

◆ merge() [1/4]

void zxeco::LinearGraphic::merge	(	size_t	destoffset,
		const LinearGraphic &	oth,
		size_t	origoffset,
		size_t	howmany,
		GraphOp	op = `GraphOp::COPY`
	)

#include <ZXGraphics.h>

Merge HOWMANY bytes from OTH (at ORIGOFFSET) into this (at DESTOFFSET).

Uses the byte operation indicated by OP. If any of the offsets get out of range, or the destination graphic is oneByte(), throws.

◆ mergeUnsafe()

void zxeco::LinearGraphic::mergeUnsafe	(	size_t	destoffset,
		const LinearGraphic &	oth,
		size_t	origoffset,
		size_t	howmany,
		GraphOp	op = `GraphOp::COPY`
	)

#include <ZXGraphics.h>

Merge HOWMANY bytes from OTH (at ORIGOFFSET) into this (at DESTOFFSET).

Uses the byte operation indicated by OP. No out of ranges are detected. If this graphic is oneByte(), do nothing.

◆ compare()

int zxeco::LinearGraphic::compare	(	const LinearGraphic &	oth,
		bool	withinv = `false`
	)		const

noexcept

#include <ZXGraphics.h>

Compare this graphic to OTH and return 1 if both are equal.

Both are considered equal if they have the same dimensions and content (byte by byte). If WITHINV == TRUE and the content are the same but inversed (one-complement) in all bytes, they are also considered equal and -1 is returned. In any case they are not equal, 0 is returned.

◆ similarity()

size_t zxeco::LinearGraphic::similarity ( const LinearGraphic & oth ) const

noexcept

#include <ZXGraphics.h>

Return a measure of the bitmap similarity (bit by bit) between both.

Similarity is defined here as the total number of bits that are equal in both graphics; the returned value will be that number of bits. This method returns 0 if both graphics have different dimensions, and std::numeric_limits<size_t>::max() if they are both empty.

◆ DimsGraphic() [1/6]

template<typename HEIGHTRESOL >

zxeco::DimsGraphic< HEIGHTRESOL >::DimsGraphic ( void )

inline

#include <ZXGraphics.h>

Default constructor: empty graphic.

Definition at line 1024 of file ZXGraphics.h.

◆ DimsGraphic() [2/6]

template<typename HEIGHTRESOL >

zxeco::DimsGraphic< HEIGHTRESOL >::DimsGraphic ( const AreaType & a )

inline

#include <ZXGraphics.h>

Construct an undefined graphic of the given dimensions, to be filled.

Definition at line 1027 of file ZXGraphics.h.

◆ DimsGraphic() [3/6]

template<typename HEIGHTRESOL >

zxeco::DimsGraphic< HEIGHTRESOL >::DimsGraphic	(	const AreaType &	a,
		uint8_t	b
	)

inline

#include <ZXGraphics.h>

Construct a graphic of the given dimensions filled with one byte (B).

Definition at line 1031 of file ZXGraphics.h.

◆ DimsGraphic() [4/6]

template<typename HEIGHTRESOL >

zxeco::DimsGraphic< HEIGHTRESOL >::DimsGraphic	(	uint8_t *	bs,
		const AreaType &	a
	)

inline

#include <ZXGraphics.h>

Construct a graphic that is held externally (NO OWNERSHIP to this).

Definition at line 1036 of file ZXGraphics.h.

◆ DimsGraphic() [5/6]

template<typename HEIGHTRESOL >

zxeco::DimsGraphic< HEIGHTRESOL >::DimsGraphic	(	DimsGraphic< HEIGHTRESOL > &	g,
		const RectType &	region,
		bool	copy = `true`
	)

#include <ZXGraphics.h>

Construct a graphic that refers to a region within another one.

If the region is empty (0 width or height), take the entire region of G from the given corner to the G boundaries.

Parameters

copy	indicates whether the region is copied into this graphic (taking ownerwhip of the copied data) or not (referring to G data and, therefore, requiring G to outlive this object). If it is copied, G is not modified by this constructor.

Definition at line 1786 of file ZXGraphics.h.

◆ DimsGraphic() [6/6]

template<typename HEIGHTRESOL >

zxeco::DimsGraphic< HEIGHTRESOL >::DimsGraphic ( DimsGraphic< HEIGHTRESOL > && oth )

inline

#include <ZXGraphics.h>

Move constructor.

Definition at line 1052 of file ZXGraphics.h.

◆ operator=() [1/2]

template<typename HEIGHTRESOL >

DimsGraphic & zxeco::DimsGraphic< HEIGHTRESOL >::operator= ( DimsGraphic< HEIGHTRESOL > && oth )

inline

#include <ZXGraphics.h>

Move assignment.

Definition at line 1056 of file ZXGraphics.h.

◆ offset()

template<typename HEIGHTRESOL >

size_t zxeco::DimsGraphic< HEIGHTRESOL >::offset ( const CursorType & pos ) const

#include <ZXGraphics.h>

Get the offset corresponding to the given coordinates in the graphic.

Throw if the coords are invalid.

Definition at line 1838 of file ZXGraphics.h.

◆ coords()

template<typename HEIGHTRESOL >

DimsGraphic< HEIGHTRESOL >::CursorType zxeco::DimsGraphic< HEIGHTRESOL >::coords ( size_t offset ) const

#include <ZXGraphics.h>

Get the coordinates of the given offset, if it is valid, or throws.

Definition at line 1850 of file ZXGraphics.h.

◆ getByte()

template<typename HEIGHTRESOL >

uint8_t zxeco::DimsGraphic< HEIGHTRESOL >::getByte ( const CursorType & pos ) const

inline

#include <ZXGraphics.h>

< Unhide the linear getByte() method hidden by the new getByte().

< Get that byte from the graphic or throw if the coordinates are wrong.

Definition at line 1072 of file ZXGraphics.h.

◆ setByte() [2/2]

template<typename HEIGHTRESOL >

void zxeco::DimsGraphic< HEIGHTRESOL >::setByte	(	const CursorType &	pos,
		uint8_t	b
	)

inline

#include <ZXGraphics.h>

< Unhide the linear setByte() method hidden by the new setByte().

Parameters

b	Change the byte at the given coordinates by the new byte B. If the graphic has ONEBYTE == TRUE or the coordinates are outside the byte, throw an exception.

Definition at line 1079 of file ZXGraphics.h.

◆ merge() [2/4]

template<typename HEIGHTRESOL >

void zxeco::DimsGraphic< HEIGHTRESOL >::merge	(	const DimsGraphic< HEIGHTRESOL > &	oth,
		const CursorType &	pos,
		GraphOp	mode = `GraphOp::COPY`
	)

#include <ZXGraphics.h>

Merge OTH at the given coordinates of this object with the given mode.

The portion of OTH that falls outside this object will be ignored. Raise an exception if this object is onebyte.

Definition at line 1859 of file ZXGraphics.h.

◆ scrollUp()

template<typename HEIGHTRESOL >

HEIGHTRESOL::type zxeco::DimsGraphic< HEIGHTRESOL >::scrollUp	(	typename HEIGHTRESOL::type	howmany,
		typename HEIGHTRESOL::type	upperrow,
		uint8_t	fillb
	)

inline

#include <ZXGraphics.h>

Scroll HOWMANY rows of the graphic up, beginning at y-coord UPPERROW.

The scroll is done all the way down to the bottom of the graphic. UPPERROW indicates the first row (i.e., the one with smallest y-coord) that is scrolled up; rows higher than that will not be scrolled, but can be overwritten by lower rows that are scrolled (depending on HOWMANY). Fill the free space left at the bottom with FILLB. Return the upper row that will fall in the visible part of the graphic after scroll: if UPPERROW < HOWMANY, that is not equal to UPPERROW, since UPPERROW dissappears through the upper border in that case.

If HOWMANY is 0 or >= the height of the graphic, do nothing. If UPPERROW >= height of the graphic, no scroll is done. If the graphic has ONEBYTE==true, do nothing.

Definition at line 1104 of file ZXGraphics.h.

◆ to_string() [6/9]

template<typename HEIGHTRESOL >

std::string zxeco::DimsGraphic< HEIGHTRESOL >::to_string ( void ) const

#include <ZXGraphics.h>

Return a text with the info of the graphic.

Definition at line 1891 of file ZXGraphics.h.

◆ graphicDimensionsTooLarge()

template<typename WIDTHRESOL , typename HEIGHTRESOL >

bool zxeco::graphicDimensionsTooLarge	(	unsigned	sx,
		unsigned	sy
	)

inlinenoexcept

#include <ZXGraphics.h>

< Return TRUE if SX,SY are too large to fit in WITHRESOL,HEIGHTRESOL.

Definition at line 1137 of file ZXGraphics.h.

◆ Bitmap()

zxeco::Bitmap::Bitmap	(	DesktopInterface &	desktop,
		const std::string &	pngfile
	)

#include <ZXGraphics.h>

< Reuse all constructor from Gr<PixelDistT>.

Construct a b&w bitmap from reading a png file and discarding color. If the image width is not a multiple of 8, takes the greatest multiple of 8 that is smaller than the image width; the rest of pixels are discarded. RGB colors with a average gray level smaller than 127 will be ink (1), otherwise paper (0). PNG transparency is ignored.

◆ merge() [3/4]

void zxeco::Bitmap::merge	(	const Bitmap &	oth,
		const PixCursor &	pos,
		GraphOp	mode = `GraphOp::COPY`
	)

#include <ZXGraphics.h>

< Unhide the base merge() method hidden by the new merge().

Merge the given graphic at the given pixel coordinates in that mode. This is an additional overload of the merge() method in the parent class. To select this overload, you can explicitly use PixCursor in the second argument, or CharPixCursor if you wish the base version. Unlike the merge() method of the parent class, this works in pixel coordinates also for the width dimension, therefore allows to place OTH at any pixel of this graphic, not only on whole char boundaries. The portion of OTH that falls outside this graphic will be ignored. Raise an exception if this graphic is onebyte.

◆ to_string() [7/9]

std::string zxeco::Bitmap::to_string ( void ) const

inline

#include <ZXGraphics.h>

Return a text with the info of the graphic.

Definition at line 1207 of file ZXGraphics.h.

◆ swapPaperInk()

void zxeco::Attrmap::swapPaperInk ( void )

#include <ZXGraphics.h>

< Reuse all constructor from Gr<CharDistT>.

Swap paper and ink in all attributed of the attrmap.

◆ to_string() [8/9]

std::string zxeco::Attrmap::to_string ( void ) const

inline

#include <ZXGraphics.h>

Return a text with the info of the graphic.

Definition at line 1237 of file ZXGraphics.h.

◆ DoubleGraphic() [1/5]

zxeco::DoubleGraphic::DoubleGraphic ( const CharArea & dims )

inline

#include <ZXGraphics.h>

Constructor for a given size in characters.

Both the bitmap and the attrmap get a size that cover the same region.

Definition at line 1301 of file ZXGraphics.h.

◆ DoubleGraphic() [2/5]

zxeco::DoubleGraphic::DoubleGraphic	(	uint8_t *	bs,
		uint8_t *	as,
		const CharArea &	a
	)

inline

#include <ZXGraphics.h>

Construct a graphic that is held externally (NO OWNERSHIP to this).

Definition at line 1307 of file ZXGraphics.h.

◆ DoubleGraphic() [3/5]

zxeco::DoubleGraphic::DoubleGraphic	(	DoubleGraphic &	g,
		const CharRect &	region,
		bool	copy = `true`
	)

inline

#include <ZXGraphics.h>

Construct a graphic that refers to the same region within a bit/attrmap.

If the region is empty (0 width or height), take the entire region of G from the given corner to the G boundaries.

Parameters

copy	indicates whether the region is copied into this graphic (taking ownerwhip of the copied data) or not (referring to G data and, therefore, requiring G to outlive this object). If it is copied, G will not be modified by this constructor.

Definition at line 1312 of file ZXGraphics.h.

◆ DoubleGraphic() [4/5]

zxeco::DoubleGraphic::DoubleGraphic	(	DesktopInterface &	desktop,
		const std::string &	pngfile,
		const PNGConversionParms &	parms = `{PNGConversionMode::ToNearestPlain, PNGConversionSubmode::None}`
	)

#include <ZXGraphics.h>

Constructor from a .png file.

Create the bitmap and the attrmap from the file. The algorithm used for deducing both is the same as in: http://jafma.net/software/zxscreen/

◆ DoubleGraphic() [5/5]

zxeco::DoubleGraphic::DoubleGraphic ( DoubleGraphic && oth )

inline

#include <ZXGraphics.h>

Definition at line 1333 of file ZXGraphics.h.

◆ operator=() [2/2]

DoubleGraphic & zxeco::DoubleGraphic::operator= ( DoubleGraphic && oth )

inline

#include <ZXGraphics.h>

Definition at line 1335 of file ZXGraphics.h.

◆ merge() [4/4]

void zxeco::DoubleGraphic::merge	(	const DoubleGraphic &	oth,
		const CharCursor &	pos,
		LinearGraphic::GraphOp	mode = `LinearGraphic::GraphOp::COPY`
	)

inline

#include <ZXGraphics.h>

Merge both bitmap and attrmap of OTH at the given coordinates in MODE.

The portion of OTH that falls outside this graphic will be ignored. Raise an exception if this bitmap or attrmap are onebyte.

Definition at line 1346 of file ZXGraphics.h.

◆ savePNG()

void zxeco::DoubleGraphic::savePNG	(	DesktopInterface &	desktop,
		const std::string &	pngfile
	)

#include <ZXGraphics.h>

Save the double graphic into a PNG file.

Raise an exception if any error in the process.

◆ to_string() [9/9]

std::string zxeco::DoubleGraphic::to_string ( void ) const

inline

#include <ZXGraphics.h>

Return a text with the info of the graphic.

Definition at line 1355 of file ZXGraphics.h.

◆ indexInPal()

RGBPalette::Index zxeco::DoubleGraphic::DitheringSystem::Color::indexInPal ( void ) const

inlinenoexcept

#include <ZXGraphics.h>

Definition at line 1406 of file ZXGraphics.h.

◆ firstExtreme()

RGBPalette::Index zxeco::DoubleGraphic::DitheringSystem::Color::firstExtreme ( void ) const

inlinenoexcept

#include <ZXGraphics.h>

Definition at line 1411 of file ZXGraphics.h.

◆ secondExtreme()

RGBPalette::Index zxeco::DoubleGraphic::DitheringSystem::Color::secondExtreme ( void ) const

inlinenoexcept

#include <ZXGraphics.h>

Definition at line 1413 of file ZXGraphics.h.

◆ ditherLevel()

DitherLevel zxeco::DoubleGraphic::DitheringSystem::Color::ditherLevel ( void ) const

inlinenoexcept

#include <ZXGraphics.h>

Definition at line 1415 of file ZXGraphics.h.

◆ notDithered()

bool zxeco::DoubleGraphic::DitheringSystem::Color::notDithered ( void ) const

inlinenoexcept

#include <ZXGraphics.h>

Definition at line 1417 of file ZXGraphics.h.

◆ equalExtremesOrder()

bool zxeco::DoubleGraphic::DitheringSystem::Color::equalExtremesOrder ( const Color & oc ) const

inlinenoexcept

#include <ZXGraphics.h>

Definition at line 1420 of file ZXGraphics.h.

◆ equalExtremesNotOrder()

bool zxeco::DoubleGraphic::DitheringSystem::Color::equalExtremesNotOrder ( const Color & oc ) const

inlinenoexcept

#include <ZXGraphics.h>

Definition at line 1423 of file ZXGraphics.h.

◆ equalExtremes()

bool zxeco::DoubleGraphic::DitheringSystem::Color::equalExtremes ( const Color & oc ) const

inlinenoexcept

#include <ZXGraphics.h>

Definition at line 1426 of file ZXGraphics.h.

◆ DitheringSystem()

zxeco::DoubleGraphic::DitheringSystem::DitheringSystem ( NumDithLevels nlvs )

inline

#include <ZXGraphics.h>

Definition at line 1452 of file ZXGraphics.h.

◆ numDithLevels()

constexpr NumDithLevels zxeco::DoubleGraphic::DitheringSystem::numDithLevels ( void ) const

inlineconstexprnoexcept

#include <ZXGraphics.h>

Definition at line 1460 of file ZXGraphics.h.

◆ maxDithLevel()

constexpr NumDithLevels zxeco::DoubleGraphic::DitheringSystem::maxDithLevel ( void ) const

inlineconstexprnoexcept

#include <ZXGraphics.h>

Definition at line 1463 of file ZXGraphics.h.

◆ inverseDithLevel()

constexpr DitherLevel zxeco::DoubleGraphic::DitheringSystem::inverseDithLevel ( DitherLevel dl ) const

inlineconstexprnoexcept

#include <ZXGraphics.h>

Definition at line 1466 of file ZXGraphics.h.

◆ numClusters()

constexpr RGBPalette::Size zxeco::DoubleGraphic::DitheringSystem::numClusters ( void ) const

inlineconstexprnoexcept

#include <ZXGraphics.h>

Definition at line 1469 of file ZXGraphics.h.

◆ totalColors()

constexpr RGBPalette::Size zxeco::DoubleGraphic::DitheringSystem::totalColors ( void ) const

inlineconstexprnoexcept

#include <ZXGraphics.h>

Definition at line 1472 of file ZXGraphics.h.

◆ deployColor() [1/2]

Color zxeco::DoubleGraphic::DitheringSystem::deployColor ( const RGBColor & rgb ) const

inline

#include <ZXGraphics.h>

Definition at line 1480 of file ZXGraphics.h.

◆ deployColor() [2/2]

Color zxeco::DoubleGraphic::DitheringSystem::deployColor ( RGBPalette::Index palind ) const

inline

#include <ZXGraphics.h>

Definition at line 1483 of file ZXGraphics.h.

◆ LinearGraphic::doGraphOp< LinearGraphic::GraphOp::INV >()

template<>

constexpr uint8_t zxeco::LinearGraphic::doGraphOp< LinearGraphic::GraphOp::INV >	(	uint8_t	b0,
		uint8_t	b1
	)

constexprnoexcept

#include <ZXGraphics.h>

Definition at line 1684 of file ZXGraphics.h.

◆ LinearGraphic::doGraphOp< LinearGraphic::GraphOp::OR >()

template<>

constexpr uint8_t zxeco::LinearGraphic::doGraphOp< LinearGraphic::GraphOp::OR >	(	uint8_t	b0,
		uint8_t	b1
	)

constexprnoexcept

#include <ZXGraphics.h>

Definition at line 1690 of file ZXGraphics.h.

◆ LinearGraphic::doGraphOp< LinearGraphic::GraphOp::INVOR >()

template<>

constexpr uint8_t zxeco::LinearGraphic::doGraphOp< LinearGraphic::GraphOp::INVOR >	(	uint8_t	b0,
		uint8_t	b1
	)

constexprnoexcept

#include <ZXGraphics.h>

Definition at line 1696 of file ZXGraphics.h.

◆ LinearGraphic::doGraphOp< LinearGraphic::GraphOp::AND >()

template<>

constexpr uint8_t zxeco::LinearGraphic::doGraphOp< LinearGraphic::GraphOp::AND >	(	uint8_t	b0,
		uint8_t	b1
	)

constexprnoexcept

#include <ZXGraphics.h>

Definition at line 1702 of file ZXGraphics.h.

◆ LinearGraphic::doGraphOp< LinearGraphic::GraphOp::INVAND >()

template<>

constexpr uint8_t zxeco::LinearGraphic::doGraphOp< LinearGraphic::GraphOp::INVAND >	(	uint8_t	b0,
		uint8_t	b1
	)

constexprnoexcept

#include <ZXGraphics.h>

Definition at line 1708 of file ZXGraphics.h.

◆ LinearGraphic::doGraphOp< LinearGraphic::GraphOp::XOR >()

template<>

constexpr uint8_t zxeco::LinearGraphic::doGraphOp< LinearGraphic::GraphOp::XOR >	(	uint8_t	b0,
		uint8_t	b1
	)

constexprnoexcept

#include <ZXGraphics.h>

Definition at line 1714 of file ZXGraphics.h.

◆ LinearGraphic::doGraphOp< LinearGraphic::GraphOp::INVXOR >()

template<>

constexpr uint8_t zxeco::LinearGraphic::doGraphOp< LinearGraphic::GraphOp::INVXOR >	(	uint8_t	b0,
		uint8_t	b1
	)

constexprnoexcept

#include <ZXGraphics.h>

Definition at line 1720 of file ZXGraphics.h.

Variable Documentation

◆ kMaxPixelCoord

constexpr PixelCoord zxeco::kMaxPixelCoord = std::numeric_limits<PixelCoord>::max()

constexpr

#include <ZXGraphics.h>

Maximum value of a pixel coordinate.

Definition at line 105 of file ZXGraphics.h.

◆ kMaxCharCoord

constexpr CharCoord zxeco::kMaxCharCoord = std::numeric_limits<CharCoord>::max()

constexpr

#include <ZXGraphics.h>

Maximum value of a char coordinate.

Definition at line 108 of file ZXGraphics.h.

◆ kMaxPixelDist

constexpr PixelDist zxeco::kMaxPixelDist = std::numeric_limits<PixelDist>::max()

constexpr

#include <ZXGraphics.h>

Maximum value of a pixel distance.

Definition at line 111 of file ZXGraphics.h.

◆ kMaxCharDist

constexpr CharDist zxeco::kMaxCharDist = std::numeric_limits<CharDist>::max()

constexpr

#include <ZXGraphics.h>

Maximum value of a char distance.

Definition at line 114 of file ZXGraphics.h.

◆ kMinIntDist

constexpr IntDist zxeco::kMinIntDist = std::numeric_limits<IntDist>::min()

constexpr

#include <ZXGraphics.h>

Minimum value of an int distance.

Definition at line 117 of file ZXGraphics.h.

◆ kMaxIntDist

constexpr IntDist zxeco::kMaxIntDist = std::numeric_limits<IntDist>::max()

constexpr

#include <ZXGraphics.h>

Maximum value of an int distance.

Definition at line 120 of file ZXGraphics.h.

◆ kMaxBorderCoord

constexpr BorderCoord zxeco::kMaxBorderCoord = std::numeric_limits<BorderCoord>::max()

constexpr

#include <ZXGraphics.h>

Maximum value of a border pixel coordinate.

Definition at line 123 of file ZXGraphics.h.

◆ kMaxBorderDist

constexpr BorderDist zxeco::kMaxBorderDist = std::numeric_limits<BorderDist>::max()

constexpr

#include <ZXGraphics.h>

Maximum value of a border pixel distance.

Definition at line 126 of file ZXGraphics.h.

◆ SCREENW

constexpr PixelDist zxeco::SCREENW = 256

constexpr

#include <ZXGraphics.h>

Width in pixels of the original zx screen.

Definition at line 186 of file ZXGraphics.h.

◆ SCREENH

constexpr PixelDist zxeco::SCREENH = 192

constexpr

#include <ZXGraphics.h>

Height in pixels of the original zx screen.

Definition at line 188 of file ZXGraphics.h.

◆ TOPBORDERH

constexpr BorderDist zxeco::TOPBORDERH = 56

constexpr

#include <ZXGraphics.h>

Height in pixels of the original zx visible border in its top section.

Note that 8 of those pixels were hidden, 56 visible.

Definition at line 190 of file ZXGraphics.h.

◆ BOTTOMBORDERH

constexpr BorderDist zxeco::BOTTOMBORDERH = 56

constexpr

#include <ZXGraphics.h>

Height in pixels of the original zx visible border in its bottom section.

Definition at line 193 of file ZXGraphics.h.

◆ LEFTBORDERW

constexpr BorderDist zxeco::LEFTBORDERW = 32

constexpr

#include <ZXGraphics.h>

Height in pixels of the original zx visible border in its left section.

Definition at line 195 of file ZXGraphics.h.

◆ RIGHTBORDERW

constexpr BorderDist zxeco::RIGHTBORDERW = 64

constexpr

#include <ZXGraphics.h>

Height in pixels of the original zx visible border in its right section.

Definition at line 197 of file ZXGraphics.h.

◆ SCREENCHARCOLS

constexpr CharDist zxeco::SCREENCHARCOLS = 32

constexpr

#include <ZXGraphics.h>

Number of char columns in the screen.

Definition at line 199 of file ZXGraphics.h.

◆ SCREENCHARROWS

constexpr CharDist zxeco::SCREENCHARROWS = 24

constexpr

#include <ZXGraphics.h>

Number of char rows in the screen.

Definition at line 201 of file ZXGraphics.h.

◆ BITMAPLEN

constexpr size_t zxeco::BITMAPLEN = 6144

constexpr

#include <ZXGraphics.h>

Length in memory (bytes) of the original zx screen bitmap.

Definition at line 203 of file ZXGraphics.h.

◆ ATTRMAPLEN

constexpr size_t zxeco::ATTRMAPLEN = 768

constexpr

#include <ZXGraphics.h>

Length in memory (bytes) of the original zx screen attrmap.

Definition at line 205 of file ZXGraphics.h.

◆ DISPLAYLEN

constexpr size_t zxeco::DISPLAYLEN = BITMAPLEN + ATTRMAPLEN

constexpr

#include <ZXGraphics.h>

Length in memory (bytes) of the original complete zx screen.

Definition at line 207 of file ZXGraphics.h.

◆ SCREENROWS

constexpr CharDist zxeco::SCREENROWS = pixelDistToCharDist(SCREENH)

constexpr

#include <ZXGraphics.h>

Number of rows in the screen of the original ZX.

Definition at line 232 of file ZXGraphics.h.

◆ SCREENCOLS

constexpr CharDist zxeco::SCREENCOLS = pixelDistToCharDist(SCREENW)

constexpr

#include <ZXGraphics.h>

Number of columns in the screen of the original ZX.

Definition at line 235 of file ZXGraphics.h.

◆ name [1/7]

constexpr const char* zxeco::CharCoordT::name = "CharC"

staticconstexpr

Name of numeric type.

Definition at line 271 of file ZXGraphics.h.

◆ value [1/7]

type zxeco::CharCoordT::value

To hold values of that type.

Definition at line 273 of file ZXGraphics.h.

◆ name [2/7]

constexpr const char* zxeco::PixelCoordT::name = "PixC"

staticconstexpr

Name of numeric type.

Definition at line 281 of file ZXGraphics.h.

◆ value [2/7]

type zxeco::PixelCoordT::value

To hold values of that type.

Definition at line 283 of file ZXGraphics.h.

◆ name [3/7]

constexpr const char* zxeco::CharDistT::name = "CharD"

staticconstexpr

Name of numeric type.

Definition at line 293 of file ZXGraphics.h.

◆ value [3/7]

type zxeco::CharDistT::value

To hold values of that type.

Definition at line 295 of file ZXGraphics.h.

◆ name [4/7]

constexpr const char* zxeco::PixelDistT::name = "PixD"

staticconstexpr

Name of numeric type.

Definition at line 305 of file ZXGraphics.h.

◆ value [4/7]

type zxeco::PixelDistT::value

To hold values of that type.

Definition at line 307 of file ZXGraphics.h.

◆ name [5/7]

constexpr const char* zxeco::IntDistT::name = "IntD"

staticconstexpr

Name of numeric type.

Definition at line 316 of file ZXGraphics.h.

◆ value [5/7]

type zxeco::IntDistT::value

To hold values of that type.

Definition at line 318 of file ZXGraphics.h.

◆ name [6/7]

constexpr const char* zxeco::BorderCoordT::name = "BorderC"

staticconstexpr

Name of numeric type.

Definition at line 326 of file ZXGraphics.h.

◆ value [6/7]

type zxeco::BorderCoordT::value

To hold values of that type.

Definition at line 328 of file ZXGraphics.h.

◆ name [7/7]

constexpr const char* zxeco::BorderDistT::name = "BorderD"

staticconstexpr

Name of numeric type.

Definition at line 338 of file ZXGraphics.h.

◆ value [7/7]

type zxeco::BorderDistT::value

To hold values of that type.

Definition at line 340 of file ZXGraphics.h.

◆ x

template<typename WRES , typename HRES >

WidthType::type zxeco::Cursor< WRES, HRES >::x

Coordinate in width (horizontally).

Definition at line 365 of file ZXGraphics.h.

◆ y

template<typename WRES , typename HRES >

HeightType::type zxeco::Cursor< WRES, HRES >::y

Coordinates in height (vertically).

Definition at line 366 of file ZXGraphics.h.

◆ width

template<typename WRES , typename HRES >

WidthType::type zxeco::Area< WRES, HRES >::width

width of the area.

Definition at line 512 of file ZXGraphics.h.

◆ height

template<typename WRES , typename HRES >

HeightType::type zxeco::Area< WRES, HRES >::height

height of the area.

Definition at line 513 of file ZXGraphics.h.

◆ corner

template<typename WRES , typename HRES >

cursor_type zxeco::Rect< WRES, HRES >::corner

Top-left corner.

Definition at line 649 of file ZXGraphics.h.

◆ area

template<typename WRES , typename HRES >

area_type zxeco::Rect< WRES, HRES >::area

Width and height.

Definition at line 650 of file ZXGraphics.h.

◆ chararea

CharArea zxeco::DoubleArea::chararea

Char resolution.

Definition at line 772 of file ZXGraphics.h.

◆ pixarea

PixArea zxeco::DoubleArea::pixarea

Pixel resolution.

Definition at line 773 of file ZXGraphics.h.

◆ charrect

CharRect zxeco::DoubleRect::charrect

Char resolution.

Definition at line 802 of file ZXGraphics.h.

◆ pixrect

PixRect zxeco::DoubleRect::pixrect

Pixel resolution.

Definition at line 803 of file ZXGraphics.h.

◆ owner_

bool zxeco::LinearGraphic::owner_

protected

Definition at line 971 of file ZXGraphics.h.

◆ s_

size_t zxeco::LinearGraphic::s_

protected

Definition at line 972 of file ZXGraphics.h.

◆ thebyte [1/2]

uint8_t zxeco::LinearGraphic::thebyte

Definition at line 983 of file ZXGraphics.h.

◆ [2/2]

uint8_t { ... } ::thebyte

Definition at line 983 of file ZXGraphics.h.

◆ bytes [1/2]

uint8_t* zxeco::LinearGraphic::bytes

Definition at line 984 of file ZXGraphics.h.

◆ [2/2]

uint8_t* { ... } ::bytes

Definition at line 984 of file ZXGraphics.h.

◆ other [1/2]

LinearGraphic* zxeco::LinearGraphic::other

Definition at line 986 of file ZXGraphics.h.

◆ [2/2]

LinearGraphic* { ... } ::other

Definition at line 986 of file ZXGraphics.h.

◆ firstoff [1/2]

size_t zxeco::LinearGraphic::firstoff

Definition at line 987 of file ZXGraphics.h.

◆ [2/2]

size_t { ... } ::firstoff

Definition at line 987 of file ZXGraphics.h.

◆ chunksize [1/2]

size_t zxeco::LinearGraphic::chunksize

Definition at line 988 of file ZXGraphics.h.

◆ [2/2]

size_t { ... } ::chunksize

Definition at line 988 of file ZXGraphics.h.

◆ gap [1/2]

size_t zxeco::LinearGraphic::gap

Definition at line 989 of file ZXGraphics.h.

◆ [2/2]

size_t { ... } ::gap

Definition at line 989 of file ZXGraphics.h.

◆ numchunks [1/2]

size_t zxeco::LinearGraphic::numchunks

Definition at line 990 of file ZXGraphics.h.

◆ [2/2]

size_t { ... } ::numchunks

Definition at line 990 of file ZXGraphics.h.

◆ dims

template<typename HEIGHTRESOL >

AreaType zxeco::DimsGraphic< HEIGHTRESOL >::dims

Dimensions of the graphic.

Definition at line 1019 of file ZXGraphics.h.

◆ mode

PNGConversionMode zxeco::DoubleGraphic::PNGConversionParms::mode

Mode for conversion.

Definition at line 1276 of file ZXGraphics.h.

◆ submode

PNGConversionSubmode zxeco::DoubleGraphic::PNGConversionParms::submode

Submode.

Definition at line 1277 of file ZXGraphics.h.

◆ numlevels [1/2]

NumDithLevels zxeco::DoubleGraphic::PNGConversionParms::numlevels

Number of dithering levels.

Usually the minimum (3) is the best for a ZX result with noise, since in ZX pixels are so large that having a lot of levels just confuses the viewer. 21 is the best for fixedpattern.

Definition at line 1281 of file ZXGraphics.h.

◆ [2/2]

NumDithLevels { ... } ::numlevels

Number of dithering levels.

Usually the minimum (3) is the best for a ZX result with noise, since in ZX pixels are so large that having a lot of levels just confuses the viewer. 21 is the best for fixedpattern.

Definition at line 1281 of file ZXGraphics.h.

◆ bitmap

Bitmap zxeco::DoubleGraphic::bitmap

Definition at line 1295 of file ZXGraphics.h.

◆ attrmap

Attrmap zxeco::DoubleGraphic::attrmap

Definition at line 1296 of file ZXGraphics.h.

◆ kMinDiths

constexpr NumDithLevels zxeco::DoubleGraphic::DitheringSystem::kMinDiths = 3

staticconstexpr

Definition at line 1385 of file ZXGraphics.h.

◆ kMaxDiths

constexpr NumDithLevels zxeco::DoubleGraphic::DitheringSystem::kMaxDiths = 101

staticconstexpr

Definition at line 1386 of file ZXGraphics.h.

◆ kNumPureColors

constexpr RGBPalette::Size zxeco::DoubleGraphic::DitheringSystem::kNumPureColors

staticconstexpr

Initial value:

=

BrightColor::NUMLINEARCOLORS - 1

zxeco::BrightColor::NUMLINEARCOLORS

static constexpr RGBPalette::Size NUMLINEARCOLORS

Number of linear colors. Black is counted twice, being equal w & w/o br.

Definition: ZXColors.h:201

Definition at line 1388 of file ZXGraphics.h.

◆ kNumColorsButBright

constexpr RGBPalette::Size zxeco::DoubleGraphic::DitheringSystem::kNumColorsButBright

staticconstexpr

Initial value:

=

BrightColor::NUMLINEARCOLORS / 2

Definition at line 1390 of file ZXGraphics.h.

◆ kClusterSizeButBright

constexpr RGBPalette::Size zxeco::DoubleGraphic::DitheringSystem::kClusterSizeButBright

staticconstexpr

Initial value:

=
                                (kNumColorsButBright - 1) *
                                kNumColorsButBright /
                                2

Definition at line 1392 of file ZXGraphics.h.

◆ kClusterSize

constexpr RGBPalette::Size zxeco::DoubleGraphic::DitheringSystem::kClusterSize

staticconstexpr

Initial value:

=

kClusterSizeButBright * 2

Definition at line 1396 of file ZXGraphics.h.

◆ DitheringSystem

friend zxeco::DoubleGraphic::DitheringSystem::Color::DitheringSystem

Definition at line 1404 of file ZXGraphics.h.

Description

Typedefs

Enumerations

Functions

Variables

Screen size constants

Typedef Documentation

◆ PixelCoord

◆ CharCoord

◆ PixelDist

◆ CharDist

◆ IntDist

◆ BorderCoord

◆ BorderDist

◆ type [1/7]

◆ type [2/7]

◆ type [3/7]

◆ coord_typeT [1/3]

◆ type [4/7]

◆ coord_typeT [2/3]

◆ type [5/7]

◆ type [6/7]

◆ type [7/7]

◆ coord_typeT [3/3]

◆ WidthType [1/2]

◆ HeightType [1/2]

◆ CharCursor

◆ PixCursor

◆ CharPixCursor

◆ BorderCursor

◆ WidthType [2/2]

◆ HeightType [2/2]

◆ CursorType [1/2]

◆ CharArea

◆ PixArea

◆ CharPixArea

◆ BorderArea

◆ cursor_type

◆ area_type

◆ CharRect

◆ PixRect

◆ CharPixRect

◆ BorderRect

◆ CursorType [2/2]

◆ AreaType

◆ RectType

◆ BaseGr [1/2]

◆ BaseGr [2/2]

◆ NumDithLevels

◆ DitherLevel

Enumeration Type Documentation

◆ GraphOp

◆ PNGConversionMode

◆ PNGConversionSubmode

Function Documentation

◆ charOfPixelX()

◆ charOfPixelY()

◆ firstPixelInCharX()

◆ firstPixelInCharY()

◆ bitOfPixelX()

◆ pixelOfCharX()

◆ pixelOfCharY()

◆ charDistToPixelDist()

◆ pixelDistToCharDist()

◆ theZero()

◆ max()

◆ Cursor() [1/2]

◆ Cursor() [2/2]

◆ newRow()

◆ newCol()

◆ incRow()

◆ zero()

◆ before()

◆ rightBelow()

◆ xDiff()

◆ yDiff()

◆ addDiff()

◆ operator==() [1/3]

◆ operator!=() [1/3]

◆ operator+() [1/2]
